Ref.
No.
Part No. Part Name &
Description
Remarks
R8647 ERJ2GE0R00 M 0 OHM, 0.063W DZ6710*
R8648 ERJ2GE0R00 M 0 OHM, 0.063W DZ6710*
R8649 ERJ2GE0R00 M 0 OHM, 0.063W DZ6710*
R8650 ERJ2GE0R00 M 0 OHM, 0.063W DZ6710*
R8651 ERJ2GE0R00 M 0 OHM, 0.063W DZ6710*
R8652 ERJ2GE0R00 M 0 OHM, 0.063W DZ6710*
R8653 ERJ2GE0R00 M 0 OHM, 0.063W DZ6710*
R8654 ERJ2GE0R00 M 0 OHM, 0.063W DZ6710*
R8655 ERJ2GE0R00 M 0 OHM, 0.063W DZ6710*
R8656 ERJ2GE0R00 M 0 OHM, 0.063W DZ6710*
R8801 ERD25VJ1R0T RESISTOR
R8802 ERJ3GEYJ223 M 22K OHM,J,1/16W
R8803 ERJ3GEYJ182 M 1.8KOHM,J,1/16W
R8804 ERJ3GEYJ472 M 4.7KOHM,J,1/16W
R8805 ERJ6GEY0R00 M 0 OHM,J,1/10W
R8806 D1HG1018A002 RESISTOR
R8807 ERJ6GEYJ101 M 100 OHM,J,1/10W
R8808 ERJ6GEYJ101 M 100 OHM,J,1/10W
R8809 ERJ6GEYG391 M 390 OHM,J,1/10W
R8810 ERJ3GEYJ223 M 22K OHM,J,1/16W
R8811 ERJ6GEYJ2R2 M 2.2 OHM,J,1/10W
R8812 ERJ3GEYJ272 M 2.7KOHMJ,J1/16W
R8813 ERJ6GEYJ101 M 100 OHM,J,1/10W
R8814 ERJ3GEYJ272 M 2.7KOHMJ,J1/16W
R8815 ERJ3GEYJ472 M 4.7KOHM,J,1/16W
R8816 ERJ3GEYJ101 M 100 OHM,J,1/16W
R8817 ERJ6GEY0R00 M 0 OHM,J,1/10W
R8818 ERJ3GEYJ101 M 100 OHM,J,1/16W
R8819 ERJ6GEYJ101 M 100 OHM,J,1/10W
R8820 ERJ6GEYJ101 M 100 OHM,J,1/10W
R8821 ERJ6GEYJ101 M 100 OHM,J,1/10W
R8822 ERJ6GEYJ101 M 100 OHM,J,1/10W
R8823 ERJ6GEYJ101 M 100 OHM,J,1/10W
R8824 ERJ6GEYJ101 M 100 OHM,J,1/10W
R8825 ERJ6GEYJ101 M 100 OHM,J,1/10W
R8826 ERJ6GEYJ101 M 100 OHM,J,1/10W
R8827 ERJ3GEYJ182 M 1.8KOHM,J,1/16W
R8828 EXB28V472J RESISTOR ARRAY
R8829 EXB28V472J RESISTOR ARRAY
R8844 ERJ3GEYJ101 M 100 OHM,J,1/16W
R8845 ERJ3GEYJ223 M 22K OHM,J,1/16W
R8846 ERJ3GEYJ333 M 33K OHM,J,1/16W
R8848 ERJ3EKF2202 RESISTOR
R8849 ERJ3EKF2202 RESISTOR
R8850 ERJ3EKF2202 RESISTOR
R8851 ERJ3EKF2202 RESISTOR
R8852 ERJ3EKF2202 RESISTOR
R8853 ERJ3EKF2202 RESISTOR
R8854 ERJ3EKF2202 RESISTOR
R8855 ERJ3EKF2202 RESISTOR
R8856 ERJ3EKF2202 RESISTOR
R8857 ERJ3EKF2202 RESISTOR
R8858 ERJ3EKF2202 RESISTOR
R8859 ERJ3EKF2202 RESISTOR
R8860 ERJ3EKF2202 RESISTOR
R8861 ERJ3EKF2202 RESISTOR
R8862 ERJ3EKF2202 RESISTOR
R8863 ERJ3EKF2202 RESISTOR
R8864 ERJ3EKF2202 RESISTOR
R8865 ERJ3EKF2202 RESISTOR
R8866 ERJ3EKF2202 RESISTOR
R8867 ERJ3EKF2202 RESISTOR
R8868 ERJ3EKF2202 RESISTOR
R8869 ERJ3EKF2202 RESISTOR
R9630 ERJ14YJ3R3 M 3.3 OHM, J,1/4W (B-PCB)
R9631 ERJ8GEYJ220 M 22 OHM, J,1/4W (B-PCB)
R9632 ERJ14YJ5R6 M 5.6 OHM, J,1/4W (B-PCB)
R9633 ERJ8GEYJ100 M 10 OHM, J,1/4W (B-PCB)
R9634 ERJ8GEYJ100 M 10 OHM, J,1/4W (B-PCB)
R9636 ERJ14YJ3R3 M 3.3 OHM, J,1/4W (B-PCB)
R9637 ERJ8GEYJ220 M 22 OHM, J,1/4W (B-PCB)
R9638 ERJ14YJ5R6 M 5.6 OHM, J,1/4W (B-PCB)
R9640 ERJ8GEYJ100 M 10 OHM, J,1/4W (B-PCB)
Ref.
No.
Part No. Part Name &
Description
Remarks
R9653 D0XGR10KA001 RESISTOR (B-PCB)
R9950 ERJ6ENF5601 M 5.6KOHM, 1/10W
R9951 ERJ3EKF1501 M 1.5KOHM, 1/16W
R9952 ERJ3EKF1501 M 1.5KOHM, 1/16W
R9953 ERJ3EKF2201 RESISTOR
R9954 ERJ6ENF3301 M 3.3KOHM, 1/10W
R9955 ERJ6ENF6801 M 6.8KOHM, 1/10W
R9956 ERJ3EKF3302 M 33KOHM, 1/16W
R9957 ERJ6ENF5601 M 5.6KOHM, 1/10W
R9958 ERJ3EKF1501 M 1.5KOHM, 1/16W
R9959 ERJ3EKF1501 M 1.5KOHM, 1/16W
R9960 ERJ3EKF2201 RESISTOR
R9961 ERJ6ENF3301 M 3.3KOHM, 1/10W
R9962 ERJ6ENF6801 M 6.8KOHM, 1/10W
R9963 ERJ3EKF3302 M 33KOHM, 1/16W
R9964 ERJ6ENF5601 M 5.6KOHM, 1/10W
R9965 ERJ3EKF1501 M 1.5KOHM, 1/16W
R9966 ERJ3EKF1501 M 1.5KOHM, 1/16W
R9967 ERJ3EKF2201 RESISTOR
R9968 ERJ6ENF3301 M 3.3KOHM, 1/10W
R9969 ERJ6ENF6801 M 6.8KOHM, 1/10W
R9970 ERJ3EKF3302 M 33KOHM, 1/16W
R9971 ERJ3GEYJ470 M 47 OHM,J,1/16W
[CAPACITORS]
C1800 F1G1C104A077 CAPACITOR
C1801 F1G1C104A077 CAPACITOR
C1802 F1G1C104A077 CAPACITOR
C1803 F1H1C104A041 CAPACITOR
C1804 F1H0J1050012 CAPACITOR
C1807 F1G1C104A077 CAPACITOR
C1808 F1J0J106A013 CAPACITOR
C1809 F1G1C104A077 CAPACITOR
C1810 F1H0J1050012 CAPACITOR
C1814 F1J0J106A013 CAPACITOR
C1815 F1G1C104A077 CAPACITOR
C1816 F1G1C104A077 CAPACITOR
C1818 ECJ1VC1H100D CAPACITOR
C1819 F1G1C104A077 CAPACITOR
C1820 F1G1C104A077 CAPACITOR
C1821 F1H0J1050012 CAPACITOR
C1822 F1G1C104A077 CAPACITOR
C1823 F1J0J106A013 CAPACITOR
C1824 F1G1C104A077 CAPACITOR
C1825 F1G1C104A077 CAPACITOR
C1826 F1G1C104A077 CAPACITOR
C1827 F1G1C104A077 CAPACITOR
C1828 F1H0J1050012 CAPACITOR
C1829 F1G1C104A077 CAPACITOR
C1830 F1J0J106A013 CAPACITOR
C1831 F1G1C104A077 CAPACITOR
C1832 F1H0J1050012 CAPACITOR
C1833 F1J0J106A013 CAPACITOR
C1834 F1G1C104A077 CAPACITOR
C1835 F1H0J1050012 CAPACITOR
C1836 F1G1C104A077 CAPACITOR
C1837 F1H0J1050012 CAPACITOR
C1838 F1G1C104A077 CAPACITOR
C1839 F1H0J1050012 CAPACITOR
C1840 F1G1C104A077 CAPACITOR
C1841 F1H0J1050012 CAPACITOR
C1842 F1G1C104A077 CAPACITOR
C1843 F1G1C104A077 CAPACITOR
C1844 F2G1C1010040 CAPACITOR
C1849 F1J0J106A013 CAPACITOR
C1850 ECJ1VC1H100D CAPACITOR
C1851 ECJ1VC1H100D CAPACITOR
C1852 F1G1C104A077 CAPACITOR
C1853 F1G1C104A077 CAPACITOR
C1854 F1J0J106A013 CAPACITOR
C1855 F1G1C104A077 CAPACITOR
C1856 F1G1C104A077 CAPACITOR
135
PT-DZ6710U / PT-DZ6710E / PT-DZ6700U / PT-DZ6700E / PT-DW6300US / PT-DW6300ES / PT-D6000US / PT-D6000ES
