Panasonic PT-DW6300ES - Page 143

Ref.
No.
Part No. Part Name &
Description
Remarks
C8646 F1G1C104A077 CAPACITOR DZ6710*
C8647 F1G1C104A077 CAPACITOR DZ6710*
C8648 F1G1C104A077 CAPACITOR DZ6710*
C8649 F1G1C104A077 CAPACITOR DZ6710*
C8650 F1G1C104A077 CAPACITOR DZ6710*
C8651 F1G1C104A077 CAPACITOR DZ6710*
C8652 F1G1C104A077 CAPACITOR DZ6710*
C8653 F1G1C104A077 CAPACITOR DZ6710*
C8654 F1G1C104A077 CAPACITOR DZ6710*
C8655 F1G1C104A077 CAPACITOR DZ6710*
C8656 F1G1C104A077 CAPACITOR DZ6710*
C8657 F1G1C104A077 CAPACITOR DZ6710*
C8658 F1G1C104A077 CAPACITOR DZ6710*
C8659 EEEHB0G101R E 100UF, 4V DZ6710*
C8660 F1G1C104A077 CAPACITOR DZ6710*
C8661 EEEHB0G101R E 100UF, 4V DZ6710*
C8662 F1G1C104A077 CAPACITOR DZ6710*
C8663 F1G1C104A077 CAPACITOR DZ6710*
C8664 F1G1C104A077 CAPACITOR DZ6710*
C8665 F1G1C104A077 CAPACITOR DZ6710*
C8666 F1H1A105A036 CAPACITOR DZ6710*
C8667 F1G1C104A077 CAPACITOR DZ6710*
C8668 F1G1H680A565 CAPACITOR DZ6710*
C8669 F1H1A105A036 CAPACITOR DZ6710*
C8670 F1G1C104A077 CAPACITOR DZ6710*
C8671 F1G1H680A565 CAPACITOR DZ6710*
C8672 F1G1C104A077 CAPACITOR DZ6710*
C8673 F1G1C104A077 CAPACITOR DZ6710*
C8674 F1G1C104A077 CAPACITOR DZ6710*
C8675 F1G1C104A077 CAPACITOR DZ6710*
C8676 F1G1C104A077 CAPACITOR DZ6710*
C8689 F1G1C104A077 CAPACITOR DZ6710*
C8690 F1G1C104A077 CAPACITOR DZ6710*
C8695 F2H0J1010009 CAPACITOR DZ6710*
C8696 F2H0J1010009 CAPACITOR DZ6710*
C8801 F1G1C104A083 CAPACITOR
C8802 F1G1C104A083 CAPACITOR
C8803 F1G1C104A083 CAPACITOR
C8804 EEEHB0J470R E 47UF, 6.3V
C8806 F1G1C104A083 CAPACITOR
C8808 F1H1C104A008 CAPACITOR
C8814 F1H1A105A036 CAPACITOR
C8815 F1H1C104A008 CAPACITOR
C8818 F1H1H103A219 CAPACITOR
C8820 F1H1C104A008 CAPACITOR
C8821 F1H1C104A008 CAPACITOR
C8822 F1H1C104A008 CAPACITOR
C8823 F1H1C104A008 CAPACITOR
C8824 F1H1C104A008 CAPACITOR
C8825 F1H1C104A008 CAPACITOR
C8826 F1H1C104A008 CAPACITOR
C8827 F1H1C104A008 CAPACITOR
C8828 F1H1C104A008 CAPACITOR
C8829 F1H1C104A008 CAPACITOR
C9610 F0C2G1050004 CAPACITOR (B-PCB)
C9615 F0C3C4720003 CAPACITOR (B-PCB)
C9618 F0C2J1540004 CAPACITOR (B-PCB)
C9619 F0C2J1540004 CAPACITOR (B-PCB)
C9950 F1H1C104A008 CAPACITOR
C9951 F1H1C104A008 CAPACITOR
C9952 EEEHB0J470R E 47UF, 6.3V
[OTHERS]
A1 K1KA06A00508 CONNECTOR
A3 K1MY16AA0006 CONNECTOR
A4 K1MN32AA0041 CONNECTOR DZ6710*/DZ6700*
A5 K1KA10A00416 CONNECTOR
A7 K1KA04A00667 4P CONNECTOR
A8 K1KA05A00466 CONNECTOR
A9 K1KA02AA0104 2P CONNECTOR
A10 K1KA02AA0150 2P CONNECTOR
A12 K1KA06A00508 CONNECTOR
Ref.
No.
Part No. Part Name &
Description
Remarks
A18 K1KA11B00092 CONNECTOR DZ6710*/DZ6700*
A19 K1KA06BA0050 CONNECTOR DZ6710*/DZ6700*
A20 K1KA10A00416 CONNECTOR
A21 K1KA04AA0264 4P CONNECTOR
A22 K1KA14A00248 CONNECTOR
A24 K1KA06AA0104 CONNECTOR
A25 K1KA06AA0104 CONNECTOR
A30 K1KA03AA0104 3P CONNECTOR
A32 K1KA03AA0104 3P CONNECTOR
A33 K1KA03AA0104 3P CONNECTOR
A35 K1KA20AA0009 CONNECTOR
A40 K1KA31A00007 CONNECTOR
A41 K1KA21A00011 CONNECTOR DZ6710*/DZ6700*
A42 K1KA06AA0150 CONNECTOR
A43 K1KA08AA0104 CONNECTOR
A44 K1KA08AA0150 CONNECTOR
A50 K1KB80A00142 CONNECTOR
A71 K1KA07AA0266 CONNECTOR DZ6710*/DZ6700*
A72 K1KA07AA0266 CONNECTOR
A75 K1KA04AA0104 4P CONNECTOR DW6300*/D6000*
A76 K1KA20AA0184 CONNECTOR
CN2401 K1KA04AA0083 4P CONNECTOR DZ6710*/DZ6700*
CW1 K1KA03AA0263 3P CONNECTOR
J1 K1MY16BA0031 CONNECTOR
J2 K1MN32BA0131 CONNECTOR DZ6710*
J3 K1KA11A00178 CONNECTOR DZ6710*
J4 K1KA06AA0150 CONNECTOR DZ6710*
J5 K1KA31A00007 CONNECTOR DZ6710*
J6 K1KA21A00011 CONNECTOR DZ6710*
J7 K1KA31A00007 CONNECTOR DZ6710*
J8 K1KA21A00011 CONNECTOR DZ6710*
J10 K1KA08AA0104 CONNECTOR DZ6710*
J13 K1KA07AA0266 CONNECTOR DZ6710*
L11 K1KA04B00273 4P CONNECTOR
L12 K1KA10A00443 CONNECTOR
L21 K1KA05B00219 CONNECTOR
L22 K1KA10A00443 CONNECTOR
RL1 K1KA20AA0009 CONNECTOR
RL3 K1KA04A00667 4P CONNECTOR
RL4 K1KA03A00632 3P CONNECTOR
RL5 K1KA04AA0104 4P CONNECTOR
RL6 K1KA03AA0104 3P CONNECTOR
RL8 K1KA07A00292 CONNECTOR
RL9 K1KA02A00787 2P CONNECTOR
RL10 K1KA06A00508 CONNECTOR
RL11 K1KA02AA0104 2P CONNECTOR
S1 K1KA06B00220 CONNECTOR
WL1 K1KA80A00145 CONNECTOR
WL2 K1KA07A00292 CONNECTOR
WL3 K1KA06BA0014 CONNECTOR
B3780 BCR20V4 BATTERY HOLDER
JK2001 K2LC108B0064 TERMINAL
JK3001 K1QBB1CB0005 BNC CONNECTOR
JK3002 K1CB204BA002 MD CONNECTOR
JK3003 K1QBB5AB0005 BNC CONNECTOR
JK3004 K1FB115B0102 CONNECTOR (D-SUB 15PIN)
JK3005 K1FB124B0026 DVI-CONNECTOR
JK8201 K1QBB1BB0014 BNC CONNECTOR DZ6710*
JK8801 K2HC103B0204 TERMINAL
JK8802 K2HC103B0203 TERMINAL
JK8803 K1FA109B0061 CONNECTOR (D-SUB 9PIN)
JK8804 K1FB109B0070 CONNECTOR (D-SUB 9PIN)
JK8805 K1FB109B0070 CONNECTOR (D-SUB 9PIN)
PC4901 B3NBB0000005 PHOTO INTERRUPTER
RM3970 B3RAD0000126 REMOTE RECEIVER
PLATE
RM9950 B3RAD0000142 REMOTE RECEIVER
PLATE
S9602 A9BZ00000013 SPARKGAP (B-PCB)
SW9601 K0BDB0000082 SWITCH
SW9950 EVQ11G05R SWITCH
SW9951 EVQ11G05R SWITCH
SW9952 EVQ11G05R SWITCH
143
PT-DZ6710U / PT-DZ6710E / PT-DZ6700U / PT-DZ6700E / PT-DW6300US / PT-DW6300ES / PT-D6000US / PT-D6000ES
