6/80
2.7. TEST PATTERN
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 54h 53h 3Ah
Character A D Z Z ; O T S :
Hexadecimal *1 *3 03h
Character *2 *4
Parameters (*1, *2, *3, *4)
OFF White Black Flag Window
Hexadecimal 30h 30h 30h 31h 30h 32h 30h 33h 30h 35h
Character 0 0 0 1 0 2 0 3 0 5
Reversed
window
Focus Colorbar RGB-3bar Red
Hexadecimal 30h 36h 30h 37h 30h 38h 31h 31h 32h 32h
Character 0 6 0 7 0 8 1 1 2 2
Green Blue 10% luminance
(White)
5% luminance
(White)
Cyan
Hexadecimal 32h 33h 32h 34h 32h 35h 32h 36h 32h 38h
Character 2 3 2 4 2 5 2 6 2 8
Magenta Yellow
Hexadecimal 32h 39h 33h 30h
Character 2 9 3 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 54h 53h 3Ah *1 *3 03h
Character O T S : *2 *4
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No Yes Yes No Yes Yes
2.8. ON SCREEN
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Fh 53h 3Ah *1 03h
Character A D Z Z ; O O S : *2
Parameters (*1, *2)
OSD OFF OSD ON
Hexadecimal 30h 31h
Character 0 1
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Fh 53h 3Ah *1 03h
Character O O S : *2
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No Yes No Yes Yes Yes
2.9. MENU key
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 4Dh 4Eh 03h
Character A D Z Z ; O M N
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 4Dh 4Eh 03h
Character O M N
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
Yes No No Ye s No Yes Yes Yes
2.10. ENTER key
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 4Fh 45h 4Eh 03h
Character A D Z Z ; O E N
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 4Fh 45h 4Eh 03h
Character O E N
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
Yes Ye s No Yes No Yes Yes Ye s
