2.51. SHIFT VERTICAL
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 54h 56h 3Ah
Character A D Z Z ; V T V :
Hexadecimal *1 *3 *5 *7 03h
Character *2 *4 *6 *8
Parameters (*1, *2, *3, *4, *5, *6, *7, *8)
1 2 3
Hexadecimal 30h 30h 30h 31h 30h 30h 30h 32h 30h 30h 30h 33h
Character 0 0 0 1 0 0 0 2 0 0 0 3
4092 4093 4094
Hexadecimal 34h 30h 39h 32h 34h 30h 39h 33h 34h 30h 39h 34h
Character 4 0 9 2 4 0 9 3 4 0 9 4
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 54h 56h 3Ah *1 *3 *5 03h
Character V T V : *2 *4 *6
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No No No No Yes No Yes Yes
Notes:
- The maximum value that can be actually set changes according to the input signal or the input resolution
settings, etc.
- For signals other than interlace, it is possible to specify it within the range from the minimum value "0" to the
maximum value "Number in which 1 is subtracted from number of total lines".
- For interlace signals, it is possible to specify it within the range from the minimum value "1" to the maximum
value "Number in which 2 is subtracted from number of total lines".
2.52. ASPECT
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 53h 45h 3Ah
Character A D Z Z ; V S E :
Hexadecimal *1 *3 03h
Character *2 *4
Parameters (*1, *2, *3, *4)
Input terminal: VIDEO, Input signal: NTSC
VID AUTO 4:3 16:9 THROUGH HV FIT
Hexadecimal 30h 31h 32h 35h 36h
Character 0 1 2 5 6
H FIT V FIT
Hexadecimal 39h 31h 30h
Character 9 1 0
Input terminal: VIDEO, Input signal: Other than NTSC
AUTO 4:3 16:9 THROUGH HV FIT
Hexadecimal 30h 31h 32h 35h 36h
Character 0 1 2 5 6
H FIT V FIT
Hexadecimal 39h 31h 30h
Character 9 1 0
Input terminal: S-VIDEO, Input signal: NTSC
VID
AUTO(PRI.)
4:3 16:9 THROUGH HV FIT
Hexadecimal 30h 31h 32h 35h 36h
Character 0 1 2 5 6
H FIT V FIT S1 AUTO VID AUTO
Hexadecimal 39h 31h 30h 32h 30h 33h 30h
Character 9 1 0 2 0 3 0
Input terminal: S-VIDEO, Input signal: Other than NTSC
AUTO 4:3 16:9 THROUGH HV FIT
Hexadecimal 30h 31h 32h 35h 36h
Character 0 1 2 5 6
H FIT V FIT
Hexadecimal 39h 31h 30h
Character 9 1 0
Input terminal: Other than VIDEO/S-VIDEO
AUTO 4:3 16:9 THROUGH HV FIT
Hexadecimal 30h 31h 32h 35h 36h
Character 0 1 2 5 6
H FIT V FIT
Hexadecimal 39h 31h 30h
Character 9 1 0
