2.69. GEOMETRY:KEYSTONE - LINEARITY
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 47h 4Dh 4Bh 49h 33h 3Dh *1 *3 *5 *7
Character G M K I 3 = *2 *4 *6 *8
Hexadecimal *9 *11 03h
Character *10 *12
Parameters (*1, *2, *3, *4, *5, *6, *7, *8, *9, *10, *11, *12)
-127 -126
Hexadecimal 2Dh 30h 30h 31h 32h 37h 2Dh 30h 30h 31h 32h 36h
Character － 0 0 1 2 7 － 0 0 1 2 6
126 127
Hexadecimal 2Bh 30h 30h 31h 32h 36h 2Bh 30h 30h 31h 32h 37h
Character + 0 0 1 2 6 + 0 0 1 2 7
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 47h 4Dh 4Bh 49h 33h
Character V X X : G M K I 3
Hexadecimal 3Dh *1 *3 *5 *7 *9 *11 03h
Character = *2 *4 *6 *8 *10 *12
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No Ye s No Yes Yes No Yes Yes
Note:
- For PT-DZ6700*/DW6300*/D6000*, ER401 is returned.
2.70. GEOMETRY:CURVED - LENS THROW RATIO
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 47h 4Dh 43h 53h 30h 3Dh *1 *3 *5 *7
Character G M C S 0 = *2 *4 *6 *8
Hexadecimal *9 03h
Character *10
Parameters (*1, *2, *3, *4, *5, *6, *7, *8, *9, *10)
0.70 0.90
Hexadecimal 30h 2Eh 37h 30h 30h 2Eh 39h 30h
Character 0 . 7 0 0 . 9 0
16.40 16.50
Hexadecimal 31h 36h 2Eh 34h 30h 31h 36h 2Eh 35h 30h
Character 1 6 . 4 0 1 6 . 5 0
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 47h 4Dh 43h 53h 30h
Character V X X : G M C S 0
Hexadecimal 3Dh *1 *3 *5 *7 *9 03h
Character = *2 *4 *6 *8 *10
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No Ye s No Yes Yes No Yes Yes
Notes:
- For PT-DZ6700*/DW6300*/D6000*, ER401 is returned.
- The character that can be specified is only a numeric and a period (decimal point).
- The parameter can specify from 0.70 to 16.50 at intervals of 0.10.
- The parameter length is variable-length.
- If the following parameters are specified, ER402 is returned.
1) The integer part is omitted.
2) The part below the decimal point is omitted.
3) Specifies three digits or more below the decimal point.
