2.73. GEOMETRY:CURVED - VERTICAL ARC
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 47h 4Dh 43h 49h 33h 3Dh *1 *3 *5 *7
Character G M C I 3 = *2 *4 *6 *8
Hexadecimal *9 *11 03h
Character *10 *12
Parameters (*1, *2, *3, *4, *5, *6, *7, *8, *9, *10, *11, *12)
-127 -126
Hexadecimal 2Dh 30h 30h 31h 32h 37h 2Dh 30h 30h 31h 32h 36h
Character － 0 0 1 2 7 － 0 0 1 2 6
126 127
Hexadecimal 2Bh 30h 30h 31h 32h 36h 2Bh 30h 30h 31h 32h 37h
Character + 0 0 1 2 6 + 0 0 1 2 7
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 47h 4Dh 43h 49h 33h
Character V X X : G M C I 3
Hexadecimal 3Dh *1 *3 *5 *7 *9 *11 03h
Character = *2 *4 *6 *8 *10 *12
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No Ye s No Yes Yes No Yes Yes
Note:
- For PT-DZ6700*/DW6300*/D6000*, ER401 is returned.
2.74. GEOMETRY:CURVED - HORIZONTAL ARC
Hexadecimal 02h 41h 44h 5Ah 5Ah 3Bh 56h 58h 58h 3Ah
Character A D Z Z ; V X X :
Hexadecimal 47h 4Dh 43h 49h 37h 3Dh *1 *3 *5 *7
Character G M C I 7 = *2 *4 *6 *8
Hexadecimal *9 *11 03h
Character *10 *12
Parameters (*1, *2, *3, *4, *5, *6, *7, *8, *9, *10, *11, *12)
-127 -126
Hexadecimal 2Dh 30h 30h 31h 32h 37h 2Dh 30h 30h 31h 32h 36h
Character － 0 0 1 2 7 － 0 0 1 2 6
126 127
Hexadecimal 2Bh 30h 30h 31h 32h 36h 2Bh 30h 30h 31h 32h 37h
Character + 0 0 1 2 6 + 0 0 1 2 7
Response (Callback)
In the period when the command can be accepted
Hexadecimal 02h 56h 58h 58h 3Ah 47h 4Dh 43h 49h 37h
Character V X X : G M C I 7
Hexadecimal 3Dh *1 *3 *5 *7 *9 *11 03h
Character = *2 *4 *6 *8 *10 *12
Acceptability
SECURITY STNDBY ECO STNDBY NO SIGNAL SHUTTER FREEZE TEST PATTERN REMOTE2
No Ye s No Yes Yes No Yes Yes
Note:
- For PT-DZ6700*/DW6300*/D6000*, ER401 is returned.
