Chapter 6 Appendix — Dimensions

ENGLISH - 183

Dimensions

Unit: mm

540 (21-1/4")

200 (7-7/8")

8.5 (11/32")

100 (3-15/16")

462 (18-3/16") 26 (1-1/32")

530 (20-7/8") 468 (18-7/16")

* Actual dimensions may differ depending on the product.
