Appendix
*1 The “i” appearing after the resolution indicates an interlaced signal.
*2 The following symbols are used to indicate picture quality.
AA Maximum picture quality can be obtained.
A Signals are converted by the image processing circuit before picture
is projected.
B Some loss of data occurs to make projection easier.
*3 Signals with “OK” in the “Resizing” column can be set using the
“RESIZING” command in the “POSITION” menu. (page 42)
*4 Signals that are compatible with the “FRAME LOCK” function. (page 42)
List of compatible signals
720 x 480i 15.7 59.9 A A OK OK Video/S-Video
720 x 576i 15.6 50.0 A A OK OK Video/S-Video
720 x 480i 15.7 59.9 13.5 A A OK OK YPBPR/RGB
720 x 576i 15.6 50.0 13.5 A A OK OK YPBPR/RGB
720 x 483 31.5 59.9 27.0 A A OK OK YPBPR/RGB
720 x 576 31.3 50.0 27.0 A A OK OK YPBPR/RGB
1 920 x 1 080i 33.8 60.0 74.3 A A YPBPR/RGB
1 920 x 1 080i 28.1 50.0 74.3 A A YPBPR/RGB
1 280 x 720 45.0 60.0 74.3 A A YPBPR/RGB
640 x 400 31.5 70.1 25.2 A A OK OK RGB
640 x 400 37.9 85.1 31.5 A A OK OK RGB
640 x 480 31.5 59.9 25.2 A A OK OK RGB
640 x 480 35.0 66.7 30.2 A A OK OK RGB
640 x 480 37.9 72.8 31.5 A A OK OK RGB
640 x 480 37.5 75.0 31.5 A A OK OK RGB
640 x 480 43.3 85.0 36.0 A A OK OK RGB
800 x 600 35.2 56.3 36.0 A AA OK RGB
800 x 600 37.9 60.3 40.0 A AA OK RGB
800 x 600 48.1 72.2 50.0 A AA OK RGB
800 x 600 46.9 75.0 49.5 A AA OK RGB
800 x 600 53.7 85.1 56.3 A AA OK RGB
832 x 624 49.7 74.6 57.3 A A OK RGB
1 024 x 768 48.4 60.0 65.0 AA A RGB
1 024 x 768 56.5 70.1 75.0 AA A RGB
1 024 x 768 60.0 75.0 78.8 AA A RGB
1 024 x 768 68.7 85.0 94.5 AA A RGB
1 024 x 768i 35.5 87.0 44.9 AA A RGB
1 152 x 864 64.0 71.2 94.2 A A RGB
1 152 x 864 67.5 74.9 108.0 B B RGB
1 152 x 864 76.7 85.0 121.5 B B RGB
1 152 x 870 68.7 75.1 100.0 B B RGB
1 280 x 960 60.0 60.0 108.0 B B RGB
1 280 x 1 024 64.0 60.0 108.0 B B RGB
1 280 x 1 024 80.0 75.0 135.0 B B RGB
1 280 x 1 024 91.1 85.0 157.5 B B RGB
1 400 x 1 050 64.0 60.0 108.0 B B RGB
1 600 x 1 200 75.0 60.0 162.0 B B RGB
