Panasonic PT-RS20K

Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 167
[MAIN/SUB VERSION] Displays the main and sub versions of the rmware of the projector.
[INTAKE AIR TEMP.]
*1
Displays the status of the intake air temperature of the projector.
[OPTICS MODULE TEMP.]
*1
Displays the status of the internal temperature of the projector.
[EXHAUST AIR TEMP.]
*1
Displays the status of the exhaust air temperature of the projector.
[LIGHT1 TEMP.]
*1
Displays the light source 1 temperature status of the projector.
[LIGHT2 TEMP.]
*1
Displays the light source 2 temperature status of the projector.
[SELF TEST] Displays the status of the projector.
[INPUT]
Displays the input terminal currently selected.
Displays the representative input terminal when one image is displayed with multiple input signals.
[SIGNAL NAME] Displays the input signal name.
[MEMORY NO.] Displays the memory number of the input signal.
[BACKUP INPUT STATUS]
Displays whether switching to the backup input signal is possible or not when [BACKUP INPUT
MODE] is set to [OFF]. (x page 119)
[NUMBER OF REGISTERED
SIGNAL]
Displays the number of registered signals.
[COOLING CONDITION] Displays the set cooling conditions.
[ATMOSPHERIC PRESSURE] Displays the atmospheric pressure.
[REMOTE2 STATUS] Displays the control status of the REMOTE2.
[AC VOLTAGE] Displays the input supply voltage.
[LENS TYPE]
*2
Displays the type name (type of the projection lens) set to the projection lens.
[LENS ID]
*2
Displays the ID set to the projection lens.
[LENS NAME]
*2
Displays the name set to the projection lens.
[LENS THROW RATIO]
*2
Displays the range of throw ratio supported by the projection lens in accordance with the [LENS
TYPE] setting.
[LENS ZOOM TYPE]
*2
Displays the drive method of the zoom motor attached to the projection lens.
[ZOOM CALIBRATION]
*2
Displays the zoom calibration result ([OK]/[FAILED]) and the calibration date.
[ON COUNT]
[POWER ON TIMES] Displays the number of times the power is turned on.
[MECHANICAL SHUTTER]
Displays the number of times the mechanical shutter is closed.
It is counted when [MECHANICAL SHUTTER] is set to [ENABLE].
[OPERATING MODE]
Displays the setting value of the [PROJECTOR SETUP] menu → [OPERATION SETTING] →
[OPERATING MODE].
[NORMAL] Displays the runtime of the light source with [OPERATING MODE] set to [NORMAL].
[ECO] Displays the runtime of the light source with [OPERATING MODE] set to [ECO].
[USER1] Displays the runtime of the light source with [OPERATING MODE] set to [USER1].
[USER2] Displays the runtime of the light source with [OPERATING MODE] set to [USER2].
[USER3] Displays the runtime of the light source with [OPERATING MODE] set to [USER3].
[CONSOLIDATED RUNTIME]
*3
Converts the total runtime of the light sources with [OPERATING MODE] set to each item into the
time used with the [NORMAL] setting.
The converted runtime is used for a rough indication about when to perform maintenance when the
projector is used in combination of each item in [OPERATING MODE].
[UPGRADE KIT]
[ET-UK20]
Displays the activation status by the Upgrade Kit (Model No.:
ET-UK20).
[ET-CUK10]
Displays the activation status by the Auto Screen Adjustment
Upgrade Kit (Model No.: ET‑CUK10).
[SIGNAL INFORMATION]
[INPUT]
Displays the input terminal used for the projected image.
Displays the representative input terminal when one image is
displayed with multiple input signals.
[SIGNAL FORMAT] Displays the format of the input signal.
[LINK]
Displays the [SDI LINK] setting.
Displays the determination result of the signal when set to [AUTO].
[2D/3D] Displays the determination results of the 2D/3D display
[SIMUL]
Displays the [SIMUL INPUT SETTING] setting.
Displays the determination result of the signal when set to
[AUTO(3D)] or [AUTO(2D)].
[COLOR FORMAT] Displays the color format of the input signal.
[SAMPLING] Displays the sampling information of the input signal.
[BIT DEPTH] Displays the gradation of the input signal.
[SIGNAL LEVEL] Displays the signal level of the input signal.
