Chapter 7 Appendix — Technical information
240 - ENGLISH
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
Format Color format Sampling
Horizontal
(kHz)
Vertical
(Hz)
2K/25p
2 048 x 1 080 28.1 25.0 74.3 3G-SDI Level-A RGB 4:4:4 10bit
2 048 x 1 080 28.1 25.0 74.3 3G-SDI Level-B RGB 4:4:4 10bit
2 048 x 1 080 28.1 25.0 74.3 3G-SDI Level-A RGB 4:4:4 12bit
2 048 x 1 080 28.1 25.0 74.3 3G-SDI Level-B RGB 4:4:4 12bit
2 048 x 1 080 28.1 25.0 74.3 3G-SDI Level-A XYZ 4:4:4 12bit
2 048 x 1 080 28.1 25.0 74.3 3G-SDI Level-B XYZ 4:4:4 12bit
2K/30p
2 048 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 10bit
2 048 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 10bit
2 048 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-A RGB 4:4:4 12bit
2 048 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-B RGB 4:4:4 12bit
2 048 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-A XYZ 4:4:4 12bit
2 048 x 1 080 33.8 30.0
*1
74.3 3G-SDI Level-B XYZ 4:4:4 12bit
2K/48p
2 048 x 1 080 54.0 48.0
*1
148.5 3G-SDI Level-A YP
B
P
R
4:2:2 10bit
2 048 x 1 080 54.0 48.0
*1
148.5 3G-SDI Level-B YP
B
P
R
4:2:2 10bit
2K/50p
2 048 x 1 080 56.3 50.0 148.5 3G-SDI Level-A YP
B
P
R
4:2:2 10bit
2 048 x 1 080 56.3 50.0 148.5 3G-SDI Level-B YP
B
P
R
4:2:2 10bit
2K/60p
2 048 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-A YP
B
P
R
4:2:2 10bit
2 048 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-B YP
B
P
R
4:2:2 10bit
*1 The signal with 1/1.001x vertical scanning frequency is also supported.
List of dual link SDI compatible signals
The following table species the dual link SDI signals that the projector can project.
Signal name
(SIGNAL FORMAT)
Resolution
(Dots)
Scanning freq.
Dot clock
freq.
(MHz)
Format Color format Sampling
Horizontal
(kHz)
Vertical
(Hz)
1080/60i
1 920 x 1 080i 33.8 60.0
*1
74.3 HD-SDI RGB 4:4:4 10bit
1 920 x 1 080i 33.8 60.0
*1
74.3 HD-SDI RGB 4:4:4 12bit
1080/50i
1 920 x 1 080i 28.1 50.0 74.3 HD-SDI RGB 4:4:4 10bit
1 920 x 1 080i 28.1 50.0 74.3 HD-SDI RGB 4:4:4 12bit
1080/24p
1 920 x 1 080 27.0 24.0
*1
74.3 HD-SDI RGB 4:4:4 10bit
1 920 x 1 080 27.0 24.0
*1
74.3 HD-SDI RGB 4:4:4 12bit
1080/24sF
1 920 x 1 080i 27.0 48.0
*1
74.3 HD-SDI RGB 4:4:4 10bit
1 920 x 1 080i 27.0 48.0
*1
74.3 HD-SDI RGB 4:4:4 12bit
1080/25p
1 920 x 1 080 28.1 25.0 74.3 HD-SDI RGB 4:4:4 10bit
1 920 x 1 080 28.1 25.0 74.3 HD-SDI RGB 4:4:4 12bit
1080/30p
1 920 x 1 080 33.8 30.0
*1
74.3 HD-SDI RGB 4:4:4 10bit
1 920 x 1 080 33.8 30.0
*1
74.3 HD-SDI RGB 4:4:4 12bit
1080/60p
1 920 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-A YP
B
P
R
4:4:4 10bit
1 920 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-B YP
B
P
R
4:4:4 10bit
1 920 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-A YP
B
P
R
4:4:4 12bit
1 920 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-B YP
B
P
R
4:4:4 12bit
1 920 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080 67.5 60.0
*1
148.5 3G-SDI Level-B RGB 4:4:4 12bit
1080/50p
1 920 x 1 080 56.3 50.0 148.5 3G-SDI Level-A YP
B
P
R
4:4:4 10bit
1 920 x 1 080 56.3 50.0 148.5 3G-SDI Level-B YP
B
P
R
4:4:4 10bit
1 920 x 1 080 56.3 50.0 148.5 3G-SDI Level-A YP
B
P
R
4:4:4 12bit
1 920 x 1 080 56.3 50.0 148.5 3G-SDI Level-B YP
B
P
R
4:4:4 12bit
1 920 x 1 080 56.3 50.0 148.5 3G-SDI Level-A RGB 4:4:4 10bit
1 920 x 1 080 56.3 50.0 148.5 3G-SDI Level-B RGB 4:4:4 10bit
1 920 x 1 080 56.3 50.0 148.5 3G-SDI Level-A RGB 4:4:4 12bit
1 920 x 1 080 56.3 50.0 148.5 3G-SDI Level-B RGB 4:4:4 12bit
