Specications
ENGLISH -
97
Appendix
Model No. PT-VW430U
PT-VX500U
PT-VX501U
Terminals
COMPUTER 1 IN/
COMPONENT IN
1 (D-sub 15 pin female)
[RGB signal] 0.7 V [p-p] 75 Ω (When G-SYNC: 1.0 [p-p] 75 Ω
HD/SYNC TTL high impedance, automatic positive/negative polarity compatible
VD TTL high impedance, automatic positive/negative polarity compatible
[YP
B
P
R
signal] Y: 1.0 V [p-p] including synchronization signal, P
B
P
R
: 0.7 V [p-p] 75 Ω
COMPUTER 2 IN/
MONITOR OUT
RGB signal] 0.7 V [p-p] 75 Ω (When G-SYNC: 1.0 [p-p] 75 Ω
HD/SYNC TTL high impedance, automatic positive/negative polarity compatible
VD TTL high impedance, automatic positive/negative polarity compatible
VIDEO IN 1 (RCA pin jack 1.0 V [p-p] 75 Ω)
S-VIDEO IN 1 (Mini DIN 4 pin, Y 1.0 V [p-p], C 0.286 V [p-p] 75 Ω, S1 signal compatible)
HDMI IN 1 (HDMI 19 pin, HDCP and Deep color compatible)
AUDIO IN
2 (M3 stereo mini jack, 0.5 V [rms], input impedance 22 kΩ and more)
1 (RCA pin jack x 2 (L-R), 0.5 V [rms], input impedance 22 kΩ and more)
VARIABLE AUDIO
OUT
1 (M3 stereo mini jack, stereo monitor output compatible,
0 V [rms] to 2.0 V [rms] valuable, output impedance 2.2 kΩ and less)
SERIAL IN 1 (D-sub 9 pin, RS-232C compliant, for computer control use
LAN 1 (for RJ-45 network connection, PJLink compatible,)
Power cable length 2.0 m(78 3/4")
Cabinet Molded plastic
Dimensions
Width: 379mm (14.92")
Height: 100 mm (3.94") (when front adjustable feet shortened)
Depth: 305 mm (12.01") (excluding protractions)
Weight Approx.4.8 kg(10.58 lbs.) *
4
Operating environment
Operating environment temperature : 5 °C (41 °F) to 40 °C (104 °F)*
5
Operating environment humidity: 20 % to 80 % (no condensation)
Remote
control
Power supply DC 3 V (battery (AAA/R03 Type ) x 2)
Operating range Approx. 7 m (275.6") (when operated directly in front of receptor)
Weight 67 g (2.36 ozs.) (including batteries)
Dimensions Width : 52 mm (2.05"), Length : 110 mm (4.33"), Height : 18 mm (0.71")
This is an average value. It may differ depending on individual product.*4 :
If [Lamp power] is set to [Normal] and the operating environment temperature exceeds 35°C(95 °F), [Lamp *5 :
power] may be changed to [Eco] automatically.
The part numbers of accessories and separately sold components are subject to change without notice.
