Panasonic SA-AK44 - Bias Frequency Adjustment (Deck 1;2); Tuner Section; AM-IF Alignment

4. Insert the CrO2 tape (QZZCRX).
5. Repeat step 2 and 3.
Bias voltage for Deck 2 14 ± 4mV (Normal)
Standard value) 17 ± 5mV (CrO2)
Erase voltage for Deck 2 more than 80mV (Normal)
more than 90mV (CrO2)
12.1.4. Bias Frequency Adjustment (Deck 1/2)
1. Set the unit to “AUX” position.
2. Insert the Normal blank tape (QZZCRA) into DECK 2 and set the
unit to “REC” mode ( use “REC/STOP” key).
3. Adjust L1002 so that the output frequency is within the standard
value.
Standard Value: 97
±8 kHz
12.2. Tuner Section
12.2.1. AM-IF Alignment
- AM-IF ALIGNMENT
