Ref. No. Part No. Part Name & Description Remarks
L803 RLBN102V-Y CHIP INDUCTOR [M]
L805 RLL500050T-Y RF CHOKE COIL [M]
L807 RLQB100JTD-D INDUCTOR [M]
L808 RLQB100JTD-D INDUCTOR [M]
L809 RLBN102V-Y CHIP INDUCTOR [M]
L1301 7L1A62N BIAS OSC COIL [M]
L2001 G1C100KA0019 CHIP INDUCTOR [M]
L2002 G1C100KA0019 CHIP INDUCTOR [M]
L2003 G1C100KA0008 CHIP INDUCTOR [M]
L3091 G1C100KA0008 CHIP INDUCTOR [M]
L3301 G1C220K00011 CHIP INDUCTOR [M]
L4211 G1C220K00011 CHIP INDUCTOR [M]
L5201 ELJEA100KF CHIP INDUCTOR [M]
L5202 ELJEA100KF CHIP INDUCTOR [M]
L5251 ELJEA100KF CHIP INDUCTOR [M]
L6501 G1C220JA0010 CHIP INDUCTOR [M]
L6502 ELJFC220KF CHIP INDUCTOR [M]
T501 ETP76VQT21HA POWER TRANSFORMER [M]
T502 RTP1H3E002 BACK UP TRANSFORMER [M]
COMPONENT COMBINATIO
Z501 ERZV10V511CS ZENER [M]
Z601 RCDRPM6937V4 REMOTE SENSOR [M]
Z971 EXBF7L355SYV RADA RESISTOR [M]
RELAY
RLY502 RSY0040M-0 PRIMARY RELAY [M]
OSCILLATORS
X451 RSXY8M00D01T CERAMIC RESONATOR [M]
X452 RSXY8M00D01T CERAMIC RESONATOR [M]
X601 RSXD32K7S02 CRYSTAL OSCILLATOR [M]
X602 H2B400400013 CRYSTAL OSCILLATOR [M]
X801 RSXZ36M8M01T CERAMIC RESONATOR [M]
X6501 VSX1044 CRYSTAL OSCILLATOR [M]
DISPLAY TUBE
FL601 RSL0311-F FL [M]
FL4201 VLF1505M105T CHIP FILTER [M]
FL6251 VLF1505M105T CHIP FILTER [M]
FL6253 VLF1505M105T CHIP FILTER [M]
FL6254 VLF1505M105T CHIP FILTER [M]
FL6255 VLF1491S104T CHIP FILTER [M]
FUSES
F1 XBA1C40NBAL FUSE [M]
FUSE HOLDERS
FC501 EYF52BC FUSE HOLDER [M]
FC502 EYF52BC FUSE HOLDER [M]
FUSE PROTECTORS
FP501 K5G402AA0002 FUSE PROTECTOR [M]
FP701 K5G402AA0002 FUSE PROTECTOR [M]
FP2001 K1MN50B00010 CONNECTOR [M]
FP3202 RJS2A7517T CONNECTOR [M]
FP3203 RJS2A7515T FMN CNNECTOR [M]
FP4202 RJS2A7526T FMN CNNECTOR [M]
FP5201 K1MN30B00062 CONNECTOR [M]
FP5202 K1MN50B00010 CONNECTOR [M]
HOLDERS
H502 RJS1A5512 12P WIRE HOLDER [M]
H521 RJS1A5510 WIRE HOLDER [M]
H601 RMR0318 9P CABLE HOLDER [M]
Ref. No. Part No. Part Name & Description Remarks
H602 RMR0315 6P CABLE HOLDER [M]
H603A RMR0318 9P CABLE HOLDER [M]
H603B RMR0318 9P CABLE HOLDER [M]
H605A RMR0315 6P CABLE HOLDER [M]
H605B RMR0315 6P CABLE HOLDER [M]
H1304 RMR0318 9P CABLE HOLDER [M]
HOL1 RMN0635 FL HOLDER [M]
HOL2 RMN0637 SENSER HOLDER [M]
EARTH TERMINAL
E500 SNE1004-2 EARTH TERMINAL [M]
E501 SNE1004-2 EARTH TERMINAL [M]
JACKS
JK201 RJH2213N JK 2P RCA PIN [M]
JK202 RJH2110N-2 JK SUB-WOOFER [M]
JK500 SJSD16-1 JK AC INLET [M]
JK501 RJR0054M-J JK SPEAKER [M]
JK502 RJR0054M-J JK SPEAKER [M]
JK503 RJH5603-9 JK SPEAKER [M]
JK603 RJJ37TK07-X JK HP/MIC [M]
JK701 RJH8203N JK VIDEO [M]
WIRES
W1 REE0863 PRI WIRE RED [M]
W1 REZ1023-1 4P WIRE [M]
W2 REE1113 FLAT WIRE [M]
W2 REZ1024 3P WIRE [M]
W500 REX1076 INLET TO PT FLAT [M]
W502 REX1071-1 TRANS TO POWER FLAT [M]
W503 REX1075 PT TO MAIN FLAT WIRE [M]
W521 REX1073 POWER TO SPEAKER [M]
W601 RWJ1109100XX PANEL TO DECK FLAT [M]
W602 REX1072 TRANS TO PANEL FLAT [M]
W603 RWJ1109230XX WIRE [M]
W605 RWJ1106100XX BABY P.T. TO MAIN [M]
W700 REX1074 2P WIRE [M]
W1304 RWJ1109140XX WIRE [M]
W1903 RWJ0102050KR WIRE [M]
RESISTORS
R1 ERDS2TJ102T 1K 1/4W [M]
R200 ERJ3GEYJ472V 4.7K 1/16W [M]
R201 ERJ3GEYJ123V 12K 1/16W [M]
R202 ERJ3GEYJ123V 12K 1/16W [M]
R203 ERJ3GEYJ122V 1.2K 1/16W [M]
R204 ERJ3GEYJ122V 1.2K 1/16W [M]
R205 ERJ3GEYJ472V 4.7K 1/16W [M]
R206 ERJ3GEYJ102V 1K 1/16W [M]
R207 ERJ3GEYJ183V 18K 1/16W [M]
R208 ERJ3GEYJ223V 22K 1/16W [M]
R211 ERJ3GEYJ102V 1K 1/16W [M]
R212 ERJ3GEYJ102V 1K 1/16W [M]
R213 ERJ3GEYJ682V 6.8K 1/16W [M]
R214 ERJ3GEYJ682V 6.8K 1/16W [M]
R215 ERJ3GEYJ682V 6.8K 1/16W [M]
R216 ERJ3GEYJ682V 6.8K 1/16W [M]
R217 ERJ3GEYJ183V 18K 1/16W [M]
R218 ERJ3GEYJ183V 18K 1/16W [M]
R219 ERJ3GEYJ272V 2.7K 1/16W [M]
R220 ERJ3GEYJ272V 2.7K 1/16W [M]
R221 ERJ3GEYJ123V 12K 1/16W [M]
R222 ERJ3GEYJ103V 10K 1/16W [M]
R223 ERJ3GEYJ272V 2.7K 1/16W [M]
R224 ERJ3GEYJ473V 47K 1/16W [M]
R225 ERJ3GEYJ392V 3.9K 1/16W [M]
R226 ERJ3GEYJ392V 3.9K 1/16W [M]
R227 ERJ3GEYJ392V 3.9K 1/16W [M]
R228 ERJ3GEYJ392V 3.9K 1/16W [M]
97
SA-DK10
