Panasonic SA-HR45E - Page 71

Ref.
No.
Part No. Part Name & Description Remarks
R5400 ERJ3GEYJ102V 1K 1/16W [M]
R5401 ERJ3GEYJ103V 10K 1/16W [M]
R5402 D0GB4R7JA007 4.7 1/16W [M]
R5403 D0GB104JA007 100K 1/16W [M]
R5404 D0GB104JA007 100K 1/16W [M]
R5405 ERJ3GEYJ682V 6.8K 1/16W [M]
R5406 D0GB105JA007 1M 1/16W [M]
R5407 D0GB220JA007 22 1/16W [M]
R5408 D0GB104JA007 100K 1/16W [M]
R5500 D0GB104JA007 100K 1/16W [M]
R5501 ERJ3GEYJ103V 10K 1/16W [M]
R5503 D0GB562JA007 5.6K 1/16W [M]
R5504 D0GB472JA007 4.7K 1/16W [M]
R5505 ERJ3GEYJ102V 1K 1/16W [M]
R5506 ERJ3GEYJ103V 10K 1/16W [M]
R5507 D0GB563JA007 56K 1/16W [M]
R5508 ERJ3GEYJ103V 10K 1/16W [M]
R5509 D0GB563JA007 56K 1/16W [M]
R5510 D0AF820JA039 82 1/4W [M]
R5512 D0GB473JA007 47K 1/16W [M]
R5513 D0GB473JA007 47K 1/16W [M]
R5700 D0GB472JA007 4.7K 1/16W [M]
R5800 D0AF1R0JA105 1 1/4W [M]
K114 D0GDR00JA017 CHIP JUMPER [M]
K115 D0GDR00JA017 CHIP JUMPER [M]
WIRES
W68 ERJ8GEY0R00V CHIP JUMPER [M]
W501 D0GDR00JA017 CHIP JUMPER [M]
W503 D0GBR00JA008 CHIP JUMPER [M]
W508 D0GDR00JA017 CHIP JUMPER [M]
W509 D0GDR00JA017 CHIP JUMPER [M]
W510 D0GDR00JA017 CHIP JUMPER [M]
W511 ERJ8GEY0R00V CHIP JUMPER [M]
W514 ERJ8GEY0R00V CHIP JUMPER [M]
W517 ERJ8GEY0R00V CHIP JUMPER [M]
W518 D0GBR00JA008 CHIP JUMPER [M]
W520 ERJ8GEY0R00V CHIP JUMPER [M]
W521 ERJ8GEY0R00V CHIP JUMPER [M]
W522 D0GBR00JA008 CHIP JUMPER [M]
W523 D0GDR00JA017 CHIP JUMPER [M]
W524 ERJ8GEY0R00V CHIP JUMPER [M]
W525 ERJ8GEY0R00V CHIP JUMPER [M]
W526 D0GDR00JA017 CHIP JUMPER [M]
W527 D0GDR00JA017 CHIP JUMPER [M]
W528 D0GBR00JA008 CHIP JUMPER [M]
W529 ERJ8GEY0R00V CHIP JUMPER [M]
W530 D0GBR00JA008 CHIP JUMPER [M]
W531 ERJ8GEY0R00V CHIP JUMPER [M]
W532 D0GDR00JA017 CHIP JUMPER [M]
W533 D0GDR00JA017 CHIP JUMPER [M]
W534 ERJ8GEY0R00V CHIP JUMPER [M]
W535 ERJ8GEY0R00V CHIP JUMPER [M]
W536 ERJ8GEY0R00V CHIP JUMPER [M]
W537 ERJ8GEY0R00V CHIP JUMPER [M]
W538 D0GDR00JA017 CHIP JUMPER [M]
W539 ERJ8GEY0R00V CHIP JUMPER [M]
W540 ERJ8GEY0R00V CHIP JUMPER [M]
W541 D0GDR00JA017 CHIP JUMPER [M]
W542 D0GDR00JA017 CHIP JUMPER [M]
W543 D0GDR00JA017 CHIP JUMPER [M]
W544 ERJ8GEY0R00V CHIP JUMPER [M]
W545 D0GBR00JA008 CHIP JUMPER [M]
W546 D0GBR00JA008 CHIP JUMPER [M]
W547 D0GDR00JA017 CHIP JUMPER [M]
W549 ERJ8GEY0R00V CHIP JUMPER [M]
W550 ERJ8GEY0R00V CHIP JUMPER [M]
W551 D0GDR00JA017 CHIP JUMPER [M]
W552 D0GDR00JA017 CHIP JUMPER [M]
W553 D0GDR00JA017 CHIP JUMPER [M]
W554 D0GBR00JA008 CHIP JUMPER [M]
Ref.
No.
Part No. Part Name & Description Remarks
W555 D0GBR00JA008 CHIP JUMPER [M]
W556 D0GBR00JA008 CHIP JUMPER [M]
W557 D0GBR00JA008 CHIP JUMPER [M]
W558 D0GBR00JA008 CHIP JUMPER [M]
W559 D0GDR00JA017 CHIP JUMPER [M]
W560 D0GDR00JA017 CHIP JUMPER [M]
W561 D0GDR00JA017 CHIP JUMPER [M]
W562 D0GBR00JA008 CHIP JUMPER [M]
W563 D0GDR00JA017 CHIP JUMPER [M]
W564 D0GBR00JA008 CHIP JUMPER [M]
W565 D0GBR00JA008 CHIP JUMPER [M]
W601 D0GBR00JA008 CHIP JUMPER [M]
W602 D0GBR00JA008 CHIP JUMPER [M]
W603 D0GBR00JA008 CHIP JUMPER [M]
W604 D0GBR00JA008 CHIP JUMPER [M]
W605 D0GBR00JA008 CHIP JUMPER [M]
W607 D0GBR00JA008 CHIP JUMPER [M]
W608 ERJ8GEY0R00V CHIP JUMPER [M]
W609 ERJ8GEY0R00V CHIP JUMPER [M]
W651 D0GBR00JA008 CHIP JUMPER [M]
W850 D0GBR00JA008 CHIP JUMPER [M]
W851 D0GBR00JA008 CHIP JUMPER [M]
WA500 D0GBR00JA008 CHIP JUMPER [M]
WA501 D0GBR00JA008 CHIP JUMPER [M]
WA502 D0GBR00JA008 CHIP JUMPER [M]
WA504 D0GBR00JA008 CHIP JUMPER [M]
WA506 D0GBR00JA008 CHIP JUMPER [M]
WA510 D0GBR00JA008 CHIP JUMPER [M]
WA511 D0GBR00JA008 CHIP JUMPER [M]
WA512 D0GBR00JA008 CHIP JUMPER [M]
WA514 D0GDR00JA017 CHIP JUMPER [M]
WA521 D0GBR00JA008 CHIP JUMPER [M]
WA524 D0GBR00JA008 CHIP JUMPER [M]
WA525 D0GBR00JA008 CHIP JUMPER [M]
WA527 D0GBR00JA008 CHIP JUMPER [M]
WA530 D0GBR00JA008 CHIP JUMPER [M]
WA531 D0GBR00JA008 CHIP JUMPER [M]
WA532 D0GBR00JA008 CHIP JUMPER [M]
WA533 D0GBR00JA008 CHIP JUMPER [M]
WA534 D0GBR00JA008 CHIP JUMPER [M]
WA535 D0GBR00JA008 CHIP JUMPER [M]
WA537 D0GBR00JA008 CHIP JUMPER [M]
WA540 D0GBR00JA008 CHIP JUMPER [M]
WA541 D0GBR00JA008 CHIP JUMPER [M]
WA542 D0GBR00JA008 CHIP JUMPER [M]
WA543 D0GBR00JA008 CHIP JUMPER [M]
CAPACITORS
C101 ECJ1VC1H821J 820P 50V [M]
C102 ECJ1VC1H821J 820P 50V [M]
C103 F1H1H101A230 100P 50V [M]
C104 F1H1H101A230 100P 50V [M]
C105 ECJ1VC1H821J 820P 50V [M]
C106 ECJ1VC1H821J 820P 50V [M]
C107 F1H1H101A230 100P 50V [M]
C108 F1H1H101A230 100P 50V [M]
C109 ECJ1VC1H821J 820P 50V [M]
C110 ECJ1VC1H821J 820P 50V [M]
C111 F1H1H101A230 100P 50V [M]
C112 F1H1H101A230 100P 50V [M]
C113 ECJ1VC1H821J 820P 50V [M]
C114 ECJ1VC1H821J 820P 50V [M]
C115 F1H1H101A230 100P 50V [M]
C116 F1H1H101A230 100P 50V [M]
C118 ECJ1VC1H821J 820P 50V [M]
C120 F1H1H101A230 100P 50V [M]
C121 ECA1HAK2R2XB 2.2 50V [M]
C122 ECA1HAK2R2XB 2.2 50V [M]
C123 ECA1HAK2R2XB 2.2 50V [M]
C124 ECA1HAK2R2XB 2.2 50V [M]
C125 ECA1HAK2R2XB 2.2 50V [M]
