Ref. No. Part No. Part Name & Description Remarks
CABINET AND CHASSIS
1 REEV0016 27P FFC [M]
2 REEV0017 19P FFC [M]
7 RGPV0008-S CASS.ORNAMENT [M]
9 RGUV0006-S FUNCTION BUTTON [M]
10 RGUV0008-S MAIN CENTRAL BUTTON [M]
11 RGUV0009-S POWER BUTTON [M]
12 RGUV0010-S FAMILY BUTTON [M]
13 RGWV0001-S VOLUME KNOB [M]
14 RHD30007-1S SCREW [M]
15 RHGV0008 LEG CUSHION [M]
16 RKF0479-1H CASS HOLDER [M]
17 RKFV0001-S CASS. LID [M]
18 RKM0445-1S SIDE PANEL (L) [M]
19 RKM0446-1S SIDE PANEL (R) [M]
20 RKMV0003-S TOP CABINET [M]
22 RKSV0002A-H REAR CABINET [M]E
22 RKSV0002B-H REAR CABINET [M]EB
22 RKSV0002-H REAR CABINET [M]EG
26 RMAV0001 MAIN PCB SUPPORT [M]
27 RMB0617 CASS OPEN SPRING [M]
28 RMBV0001 EARTH SPRING [M]
29 RMK0498 BTM CHASSIS [M]
30 RMNV0004 LCD HOLDER [M]
31 RMNV0006 AC LED HOLDER [M]
32 RMRV0002 LCD DIFUSSER SHEET [M]
33 RMRV0003 LCD LIGHTING PANEL [M]
34 RMVV0017 LCD LIGHTING COVER [M]
35 RFKGAPM10EBS FRONT PANEL ASS’Y [M]
36 RSCV0001 TUNER SHIELD (FRONT) [M]
37 RSCX0056 TUNER ANTENNA SHIELD [M]
38 RUS757ZAA CASS HALF SPRING [M]
39 RXXV0003 HEAT SINK UNIT [M]
40 SHE187-4J POWER PCB SUPPORT [M]
41 XTB3+10JFZ SCREW [M]
42 XTB3+20JFZ SCREW [M]
43 XTB3+8JFR1 SCREW [M]
44 XTB3+8JFZ SCREW [M]
45 XTBS26+10J SCREW [M]
46 XTV3+10G SCREW [M]
47 XTV3+8F SCREW [M]
48 RDG0357 DAMPER GEAR [M]
49 RFKLAPM10EBS CD LID ASS’Y [M]
20.4. Electrical Part List
