Panasonic SA-PM10 - Page 66

Ref. No. Part No. Part Name & Description Remarks
PRINTED CIRCUIT BOARD
REPX0362A CD SERVO P.C.B. [M](RTL)
REPX0004A MAIN P.C.B. [M](RTL)
REPV0003A PANEL P.C.B. [M](RTL)
REPX0350C DECK P.C.B. [M](RTL)
REPX0321H DECK MECHANISM P.C.B. [M](RTL)
REPV0005A SPEAKER TERMINAL P.C.B. [M](RTL)E/EG
REPV0005B SPEAKER TERMINAL P.C.B. [M](RTL)EB
REPV0005A HEADPHONE P.C.B. [M](RTL)E/EG
REPV0005B HEADPHONE P.C.B. [M](RTL)EB
REPX0350C TAPE EJECT P.C.B. [M](RTL)
REPV0005A POWER P.C.B. [M](RTL)E/EG
REPV0005B POWER P.C.B. [M](RTL)EB
REPV0005A TRANSFORMER P.C.B. [M](RTL)E/EG
REPV0005B TRANSFORMER P.C.B. [M](RTL)EB
INTEGRATED CIRCUITS
IC1 LA1833NMNTLM IC IF & MPX [M]
IC2 LC72131MDTRM IC PLL [M]
IC501 AN7194K-LD IC BTC POWER [M]
IC701 AN22004A-NF IC HEAD AMP [M]
IC702 MN662790RSC IC LSI [M]
IC703 BA5948FPE2 IC 4 CH DRIVE [M]
IC800 C1BB00000757 IC ASP [M]
IC801 C1BB00000715 IC RDS [M]
IC802 S81333HG-Z IC REG [M]
IC901 MN101C57DAA IC MICRO PROCESSOR [M]
IC971 CNB13030R2AU IC PHOTO INTERRUPTOR [M]
IC1000 C1AA00000612 IC ANALOG SW [M]
IC1001 AN7326K IC DECK R/P [M]
TRANSISTORS
Q1 B1AAAD000014 TRANSISTOR [M]
Q2 B1AAAD000014 TRANSISTOR [M]
Q3 2SC3311ARTA TRANSISTOR [M]
Q6 KRA102MTA TRANSISTOR [M]
Q361 KTC3199GRTA TRANSISTOR [M]
Q362 KTC3202YTA TRANSISTOR [M]
Q500 KRA110MTA TRANSISTOR [M]
Q501 KTC3199GRTA TRANSISTOR [M]
Q502 2SD0592ARA TRANSISTOR [M]
Q503 KTA1046 TRANSISTOR [M]
Q504 KTC3199GRTA TRANSISTOR [M]
Q505 KTC3199GRTA TRANSISTOR [M]
Q506 KTA1046 TRANSISTOR [M]
Q600 KTC3199GRTA TRANSISTOR [M]
Q601 2SC3940ARA TRANSISTOR [M]
Q602 KRC102MTA TRANSISTOR [M]
Q701 2SA1037AKSTX TRANSISTOR [M]
Q800 KTA1266GRAT TRANSISTOR [M]
Q801 KRC104MTA TRANSISTOR [M]
66
