“ATTENTION SERVICER”
Some chassis components may have sharp edges.
Be careful when disassembling and servicing.
1. This section describes procedures for checking the operation of
the major printed circuit boards and replacing the main
components.
2. For reassembly after operation checks or replacement, reverse the
respective procedures.
Special reassembly procedures are described only when required.
3. Select items from the following index when checks or replacement
are required.
Contents
- Disassembly and assembly main unit
1. Checking of the Main, Panel, Deck and Power P.C.B.
- Main Component Replacement Procedures
1. Replacement of the Traverse Deck.
2. Replacement of the Power Amplifier IC.
- Disassembly and assembly of the Traverse Unit
- Disassembly and assembly of the Disc Tray
Warning:
This product uses a laser diode. Refer to caution statement
Precaution of Laser Diode.
11
To Next Page
