General
Power supply AC 230 V, 50 Hz
Power consumption 100 W
Dimensions (W x H x D) 179 x 241 x 375 mm
Mass 5.6 kg
Power consumption in standby
mode
Approx. 0.7 W
System: SC-PM17(E)
Music Center: SA-PM17(E)
Speaker: SB-PM17(P)
System: SC-PM17(EB)
Music Center: SA-PM17(EB)
Speaker: SB-PM17(P)
System: SC-PM17(EG)
Music Center: SA-PM17(EG)
Speaker: SB-PM17(EG)
Notes:
1. Specifications are subject to change without notice. / Mass and
dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
1. Before Repair and Adjustment
Disconnect AC power, discharge Power Supply Capacitors C506, C507, C508, C576, C577, C587,
C588, C615 through a 10 , 5 W resistor to ground. DO NOT SHORT-CIRCUIT DIRECTLY (with a
screw driver blade, for instance), as this may destroy solid state devices.
After repairs are completed, restore power gradually using a variac, to avoid over current.
Current consumption at AC 230 V, 50 Hz in NO SIGNAL mode should be ~300 mA.
2. Protection Circuitry
The protection circuitry may have operated if either of the following conditions are noticed:
- No sound is heard when the power is turned on.
- Stops during a performance.
The function of this circuitry is to prevent circuitry damage if, for example, the positive and
negative speaker connection wires are “shorted”, or if speaker systems with an impedance less
than the indicated rated impedance of the amplifier are used.
If this occurs, follow the procedure outlines below:
1. Turn off the power.
3
