No. Mark I/O Function
76 RSEL I RF signal polarity
assignment input (at
"H" level, RSEL="H",
at "L" level, RESL=
"L")
77 IOVOD I 5V supply input
78 PSEL I Test terminal
(connected to Gnd)
79 MSEL I SMCK oscillating
frequency
designation input (“L”
:4.2336 MHz, “H”:
8.4672 MHz)
80 SSEL I SUBQ output mode
select (“H”:Q-code
buffer mode)
18.3. IC703 (BA5948FPE2) Focus coil/ Tracking coil/ Traverse motor/
Spindle motor driver
No. Mark I/O Function
1 /RST - RESET output terminal
2 NC - N.C.
3 IN2 I Motor Drive (2) input
4 PC2 I Turntable motor drive
signal (“L :ON)
5 NC - N.C.
6 IN1 I Motor driver (1) input
7 NC I N.C.
8 PVCC1 I Power supply (1) for
driver
9 PGND1 - Ground connection (1) for
driver
10 NC - N.C.
11 D1- O Motor driver (1) reverse-
action output
12 D1+ O Motor driver (1) forward-
action output
13 D2- O Motor driver (2) reverse-
action output
14 D2+ O Motor driver (2) forward-
action output
15 D3- O Motor driver (3) reverse-
action output
16 D3+ O Motor driver (3) forward-
action output
72
