Panasonic SA-PM17E - Page 86

Ref. No. Part No. Part Name & Description Remarks
53 XTW3+15T SCREW [M]
54 RGCX0005-W L/PIECE REFLECTOR [M]
55 RDG0357 DAMPER GEAR [M]
56 XTWS3+8T SCREW [M]
19.4. Components Parts List
Ref. No. Part No. Part Name & Description Remarks
P.C.B.
REP2807D CD SERVO P.C.B. [M]
REPX0289A DECK P.C.B. [M]
REPX0108G DECK MECHANISM P.C.B. [M]
REPX0278E TACT SWITCH P.C.B. / HEADPHONE P.C.B. / MAIN/TUNER P.C.B. /
TERMINAL P.C.B. / POWER-ON P.C.B. / DECK EJECT P.C.B. /
PANEL P.C.B.
REPX0279D POWER P.C.B. / AC TRANSFORMER P.C.B. [M]EB
REPX0279C POWER P.C.B. / AC TRANSFORMER P.C.B. [M]E EG
REP3340A CD LOADING P.C.B. [M]
INTEGRATED CIRCUITS
IC11 C0GAG0000007 IC DRIVER [M]
IC21 C0GAG0000007 IC DRIVER [M]
IC101 LA1833NMNTLM IC IF & MPX [M]
IC102 LC72131MDTRM IC PLL [M]
IC301 C1BB00000617 IC [M]
IC302 C1BB00000527 IC RDS [M]
IC500 RSN314H41A-P IC POWER AMP HIC [M]
IC501 C0AABB000117 IC OP-AMP (HP AMP) [M]
IC600 C2BBGF000357 IC MICROPROCESSOR [M]
IC701 AN8885SBE1 IC HEAD AMP [M]
IC702 MN662790RSC IC LSI [M]
IC703 BA5948FPE2 IC 4 CH DRIVE [M]
IC951 CNB13030R2AU IC PHOTO INTERUPTOR [M]
IC1000 C1AA00000612 IC ANALOG SW [M]
IC1001 AN7326K IC DECK R/P [M]
TRANSISTORS
Q1 B3NAA0000068 TRANSISTOR [M]
Q101 2SC2058SPTA TRANSISTOR [M]
Q102 2SC2058SPTA TRANSISTOR [M]
Q106 KRA102MTA TRANSISTOR [M]
Q110 2SC3311ARTA TRANSISTOR [M]
Q501 KTC2026 TRANSISTOR
[M]
Q502 KTA1046 TRANSISTOR [M]
Q503 KTA12710YTA TRANSISTOR [M]
Q505 KTA1267GRTA TRANSISTOR [M]
Q506 KTA1046 TRANSISTOR [M]
Q507 KTC3199GRTA TRANSISTOR [M]
Q508 KTC3199GRTA TRANSISTOR
[M]
Q509 KRA110MTA TRANSISTOR [M]
