Panasonic SB-WA730GCP

15.2. Electrical Parts List
Ref. No. Part No. Part Name & Description Remarks
PRINTED CIRCUIT BOARD
REPX0480A POWER P.C.B./ AC INLET
P.C.B./ TRANSFORMER P.C.B.
/VOLTAGE SELECTOR P.C.B.
[M] RTL
INTEGRATED CIRCUITS
IC501 RSN311W64D-P IC HIC (PBF) [M]
TRANSISTORS
Q501 B1AACF000089 TRANSISTOR [M]
Q502 B1AACF000089 TRANSISTOR [M]
Q503 B1AACF000089 TRANSISTOR [M]
Q505 B1AACF000089 TRANSISTOR [M]
Q506 B1GCCFJJ0015 TRANSISTOR [M]
Q511 B1BACG000036 TRANSISTOR [M]
Q512 B1BCCG000021 TRANSISTOR [M]
Q515 B1AACF000089 TRANSISTOR [M]
Q516 B1GACFJJ0016 TRANSISTOR [M]
Q517 B1BACG000036 TRANSISTOR [M]
Q518 B1AAGC000007 TRANSISTOR [M]
Q519 B1AACF000089 TRANSISTOR [M]
Q520 B1GCCFJJ0015 TRANSISTOR [M]
Q552 B1ACCF000063 TRANSISTOR [M]
Q553 2SD0592ARA TRANSISTOR [M]
Q554 B1ACCF000063 TRANSISTOR [M]
Q555 2SD0592ARA TRANSISTOR [M]
Q556 B1ACCF000063 TRANSISTOR [M]
Q557 2SD0592ARA TRANSISTOR [M]
DIODES
D500 B0AACK000004 DIODE [M]
D501 B0JAPG000019 DIODE [M]
D502 B0JAPG000019 DIODE [M]
D503 MA2C700A0F DIODE [M]
D504 B0AACK000004 DIODE [M]
D508 B0AACK000004 DIODE [M]
D509 B0BA5R100013 DIODE [M]
D510 B0BA5R600016 DIODE [M]
D525 B0BA7R000005 DIODE [M]
D527 B0EAKM000122 DIODE [M]
D528 B0EAKM000122 DIODE [M]
D529 MA2C700A0F DIODE [M]
D530 B0EAKM000122 DIODE [M]
D534 B0AACK000004 DIODE [M]
D555 B0AACK000004 DIODE [M]
D556 B0BA01100004 DIODE [M]
D557 B0EAKM000117 DIODE [M]
D558 B0AACK000004 DIODE [M]
D559 B0AACK000004 DIODE [M]
D560 B0AACK000004 DIODE [M]
D561 B0BA01100004 DIODE [M]
D562 B0AACK000004 DIODE [M]
D563 B0BA01900005 DIODE [M]
D564 B0BA01900005 DIODE [M]
D565 B0BA01900005 DIODE [M]
D566 B0BA01900005 DIODE [M]
D597 B0FBAM000009 DIODE [M]
D598 B0FBAM000009 DIODE [M]
D599 B0FBAM000009 DIODE [M]
SWITCHE
S500 K0AFZA000005 VOLTAGE SELECTOR [M]
CONNECTORS
CN501 K1FB125B0095 SYSTEM CONNECTOR [M]
CN502 K1KB07B00020 7P CONNECTOR [M]
Ref. No. Part No. Part Name & Description Remarks
CN503 K1KA15A00159 15P CONNECTOR [M]
CN506 K1KA04A00105 4P CONNECTOR [M]
CN507 K1KA02A00008 2P CONNECTOR [M]
CP502 K1KA07A00123 7P CONNECTOR [M]
T501 G4C8AHK00005 POWER TRANSFORMER [M]
T502 G4C2AAJ00005 SUB-TRANSFORMER [M]
COMPONENT COMBINATION
Z501 ERZV10V511CS ZENER [M]
SPEAKER
SP1 EAS13PL21A SPEAKER UNIT [M]
RELAY
RLY501 K6B1AEA00003 POWER RELAY [M]
FUSES
F1 K5D312BK0010 3.15A FUSE [M]
F2 K5D202BK0005 250V 2A FUSE [M]
FUSE HOLDERS
FC501 EYF52BCY FUSE HOLDER [M]
FC502 EYF52BCY FUSE HOLDER [M]
FC503 EYF52BCY FUSE HOLDER [M]
FC504 EYF52BCY FUSE HOLDER [M]
FUSE PROTECTOR
FP1 K5G502AA0002 5A FUSE PROTECTOR [M]
HOLDER
H503 K1YF15000004 15P WIRE HOLDER [M]
JACKS
JK500 K2AA2B000009 JK AC OUTLET [M]
JK501 K4BC06B00055 JK SPEAKER TERMINAL [M]
JK502 K4BC04B00107 JK SPEAKER [M]
EARTH TERMINALS
E500 K4CZ01000027 TERMINAL [M]
E501 K4CZ01000027 TERMINAL [M]
WIRES
W1 REEX0459 PRIMARY WIRE (BROWN) [M]
W2 REEX0458 PRIMARY WIRE (BLUE) [M]
W503 REXX0456 15P WIRE [M]
RESISTORS
R401 ERDS2TJ224T 220K 1/4W [M]
R402 ERDS2TJ102T 1K 1/4W [M]
R501 ERDS2TJ472T 4.7K 1/4W [M]
R502 ERDS2TJ472T 4.7K 1/4W [M]
R503 ERDS2TJ153T 15K 1/4W [M]
R504 ERDS2TJ153T 15K 1/4W [M]
R505 ERDS2TJ153T 15K 1/4W [M]
R506 ERDS2TJ153T 15K 1/4W [M]
R507 ERDS2TJ392T 3.9K 1/4W [M]
R508 ERDS2TJ392T 3.9K 1/4W [M]
R509 ERDS2TJ472T 4.7K 1/4W [M]
R510 ERDS2TJ472T 4.7K 1/4W [M]
R511 ERDS2TJ153T 15K 1/4W [M]
R512 ERDS2TJ153T 15K 1/4W [M]
30
SB-WA730GCP
