Before using
RQT6734
6
(4Ω)
AM ANT
Set-up
Connect the AC adaptor only after all other connections have been made.
Preparation
Twist and pull off the vinyl tip of the speaker cords.
3 AC adaptor
Use only the supplied speakers.
The combination of the main unit and speakers provide the best
sound. Using other speakers can damage the unit and sound quality
will be negatively affected.
Copper (+)
Black
Red
Silver (–)AC adaptor
(included)
Note
• The configuration of the AC adaptor differs according to the area.
Silver (–)
Red
Black
2 Speaker cords
1 AM loop antenna
Stand the antenna up on its base.gfsjkgn
Copper (+)
06-07 SC-SC-EN5 P [En] 1/13/03, 2:38 PM6
To Next Page
