Panasonic SC-HC49

22
RQT9883
Specifications

≥ Specifications are subject to change without notice.
≥ Mass and dimensions are approximate.
≥ Total harmonic distortion is measured by a digital spectrum
analyzer.
*1: “BLUETOOTH STANDBY” is “OFF”.
*2: No device is connected to the port or the dock before
turning to standby mode.
*3: MPEG-1 Layer 3, MPEG-2 Layer 3
∫ GENERAL
Power consumption 37 W
Power consumption in standby mode*
1, 2
Approx. 0.2 W
(When “BLUETOOTH STANDBY” is “ON”)*
2
Approx. 0.3 W
Power supply
(For Australia and New Zealand)
AC 220 V to 240 V, 50 Hz
(For Asia and the Middle East)
AC 110 V to 240 V, 50/60 Hz
Dimensions (WkHkD)
500 mmk205 mmk92 mm
Mass Approx. 2.5 kg
Operating temperature range
0 oC to r40 oC
Operating humidity range
35 % to 80 % RH (no condensation)
∫ AMPLIFIER SECTION
Output power
RMS Output Power Stereo mode
Front Ch (both ch driven)
20 W per channel (8 ≠), 1 kHz, 10 % THD
Total RMS Stereo mode power
40 W
(For Asia and the Middle East)
PMPO output power 450 W
∫ TUNER SECTION
Preset Memory FM 30 stations
[SC-HC49] (Australia and New Zealand only) AM 15 stations
Frequency Modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals
75 ≠ (unbalanced)
[SC-HC49] (Australia and New Zealand only)
Amplitude Modulation (AM)
Frequency range
522 kHz to 1629 kHz (9 kHz step)
520 kHz to 1630 kHz (10 kHz step)
∫ [SC-HC49DB] DAB SECTION
DAB memories 20 channels
Frequency Band (Wavelength)
Band III 5A to 13F
(174.928 MHz to 239.200 MHz)
Sensitivity *BER 4x10
-4
Min Requirement s98 dBm
DAB External Antenna
Te rmina l F - Connector (75 ≠)
∫ DISC SECTION
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3*
3
)
Pick up
Wavelength 790 nm (CD)
∫ SPEAKER SYSTEM SECTION
Speaker unit(s)
Full range
6.5 cm Cone typek1 per channel
Passive Radiator
8cmk2 per channel
Impedance 8 ≠
∫ TERMINAL SECTION
Dock connection
DC OUT 5V1.0A
Port connection
DC OUT 5V2.1A
USB Standard
USB 2.0 full speed
Media file format support
MP3 (¢.mp3)
USB device file system
FAT12 , FAT16, FAT32
∫ BLUETOOTH SECTION
Version Bluetooth
®
Ver.2.1+EDR
Class Class 2
Supported Profiles
A2DP, AVRCP
Operating Frequency
2.4 GHz band FH-SS
Operation Distance
10 m Line of sight
