Panasonic SC-HC49 User Manual

8
RQT9883
You can change the transmission mode to prioritise
transmission quality or sound quality.
Preparation
≥ Press [ ] to select “BLUETOOTH”.
≥ If a Bluetooth
®
device is already connected,
disconnect it.
1 Press [PLAY MENU] repeatedly to select
“LINK MODE”.
2 Press [3, 4] to select the mode and then press
[OK].
MODE 1: Emphasis on connectivity
MODE 2: Emphasis on sound quality

≥ Select “MODE 1” if the sound is interrupted.
≥ The factory default is “MODE 2”.
If the sound input level from the Bluetooth
®
device is
too low, change the input level setting.
Preparation
≥ Connect a Bluetooth
®
device.
1 Press [PLAY MENU] repeatedly to select “INPUT
LEVEL”.
2 Press [3, 4] to select the level and then press
[OK].
“LEVEL 0”
,. “LEVEL i1” ,. “LEVEL i2”
^---------------------------------------------------------J

≥ Select “LEVEL 0” if the sound is distorted.
≥ The factory default is “LEVEL 0”.
1 While a Bluetooth
®
device is connected:
Press [PLAY MENU] repeatedly to select
“DISCONNECT?”.
2 Press [3, 4] to select “OK? YES” and then press
[OK].

≥ You can also disconnect the Bluetooth
®
device by pressing
and holding [ -PAIRING] on the unit.
≥ The Bluetooth
®
device will be disconnected if a different
audio source (e.g., “CD”) is selected.
Media playback controls
The following marks indicate the availability of the
feature.
Preparation
≥ Turn the unit on.
≥ Insert the media or connect the Bluetooth
®
device.
≥ Press [CD/RADIO], [iPod/USB] or [ ] to select the
audio source.

≥ When using iPhone/iPad/iPod, the operation may vary
among those models.
Bluetooth
®
transmission mode
Bluetooth
®
input level
Disconnecting a Bluetooth
®
device
[CD]: CD audio in CD-DA format and a CD that
contains MP3 files (l 18)
[iPod]: Compatible iPhone/iPad/iPod (l 18)
[USB] : USB devices containing MP3 files (l 18)
[Bluetooth]: Connected Bluetooth
®
device
Basic controls
(
[CD], [iPod], [USB], [Bluetooth])
Play Press [1/;].
Stop Press [∫].
≥ [USB]: The position is memorised and
“RESUME” is displayed.
Pause Press [1/;].
Press again to restart play.
Skip Press [:/6] or [5/9] to skip
track.
[CD], [USB] Press [3] or [4] to skip the
MP3 album.
Search During play or pause, press and hold
[:/6] or [5/9].
≥ [iPod]: Backwards search is only within the
current track.
SC-HC49DBGN&GN&GS~RQT9883-B.book 8 ページ ２０１４年２月２１日 金曜日 午前９時２６分

Panasonic SC-HC49 Specifications

General

MP3 playback	Yes
Card reader integrated	-
Audio formats supported	MP3
Supported radio bands	FM
Preset stations quantity	30
Type	Home audio micro system
Cassette deck	No
Product color	Silver
USB 2.0 ports quantity	1
Apple docking compatibility	iPhone 5, iPhone 5c, iPhone 5s, iPod Touch 5
Power source	AC
Input voltage	220-240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.2 W
Power consumption (typical)	37 W
Speaker type	1-way
RMS rated power	- W
Mid-range driver diameter	65 mm

Weight and Dimensions

Depth	92 mm
Width	500 mm
Height	205 mm
Weight	2500 g
