14
VQT5J46
Additionally required accessories (commercially available)
≥Fall prevention cord ..................................................................................................................... k 1
≥Screw eye (to attach the fall prevention cord)............................................................................... k 1
≥ Use commercially available screws that are capable of supporting over 33 kg.
≥ Use a cord that is capable of supporting over 10 kg (with a diameter of about 2 mm).
Slide the MULTI ANGLE switch to “RACK/TABLE TOP”.
≥Press the AC mains lead into the holder.
Attach the cord to the main unit.
A Cord
§
§ If the cord cannot be threaded through the holes, try bending the cord in 2 locations,
about 5 mm apart from the tip, at an angle of 45
o
(as
illustrated above).
Place the main unit in the desired position and attach the cord onto the rack or table.
≥ Make sure that the slack of the cord is minimal.
≥ Do not lean the main unit against the TV or wall.
≥ Do not place the main unit over the AC mains lead.
≥ Ensure that the main unit is stable.
B Screw eye
≥Attach at a position capable of supporting over 10 kg.
≥Depending on the placement of the main unit, the screwing position of the screw eye may differ.
When placing the main unit on a rack or on a table
SC-HTB18_EB_VQT5J46.book 14 ページ ２０１４年３月１９日 水曜日 午前９時４７分
