Model No. : SC-HTB488EB/EG,494EG,498EB Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
1 TTPA0752 FRONT CABINET UNIT 1 488EG,494EG,488EB
1 TTPA0762 FRONT CABINET UNIT 1 498EB
2 RFKBT488MNV MAIN P.C.B. UNIT 1 488EG,494EG,488EB
2 RFKBT498MNV MAIN P.C.B. UNIT 1 498EB
3 TNPA6565 POWER P.C.B. 1
4 TNPA6566 KEY P.C.B. 1
5 RFKBT488LAV LED P.C.B. UNIT 1 488EG,488EB
5 RFKBT494LAV LED P.C.B. UNIT 1 494EG
5 RFKBT498LAV LED P.C.B. UNIT 1 498EB
6 TNMX065 CORD (A) 1
7 TNMX066 CORD (B) 1
8 TNMX067 CORD (C) 1
9 TNMX068 CORD (D) 1
10 TKXA30701 WIRE HOLDER 2
11 TMKB429 EVA 1
12 RFZA0021 SPEAKER 2
13 TMKK671 PROTECTION PAD 2
14 TNMX069 FFC (A) 1
15 TTFA0369 BACK CABINET UNIT 1 488EG,488EB
15 TTFA0377 BACK CABINET UNIT 1 494EG
15 TTFA0376 BACK CABINET UNIT 1 498EB
15-1 RKA0327-K RUBBER LEG 4
15-2 TMKE194 PC SHEET 1
16 TKXA30801 KEY BUTTON 1
17 RSQ0143 AC CORD 1 488EG,494EG
17 RSQ0144 AC CORD 1 488EB,498EB
101 THEC307C SILVER SCREW (B) 3
102 RHD30234-1 BLACK SCREW (A) 16
103 THEJ071Z BLACK SCREW (B) 1
104 THEC306C BLACK SCREW (C) 5
