Model No. : SC-HTB488EB/EG,494EG,498EB Parts List
Change Safety
Ref.
No.
Part No. Part Name & Description Q'ty Remarks
31 TTPA0753 SUBWOOFER BOX UNIT 1
31-1 TBMX4181 RUBBER LEG 4
32 TNPA6570 MAIN P.C.B. 1
33 TNPA6571 POWER P.C.B. 1
34 TENH5009 BRACKET (L) 1
35 TENH5010 BRACKET (R) 1
36 TEKX097 BACK PANEL UNIT 1 488EG
36 TEKX098 BACK PANEL UNIT 1 488EB
37 TEFX5008 I/D SET BUTTON 1
38 RFZA0020 WOOFER SPEAKER 1
39 TKXA30901 WOOFER SPEAKER COVER 1
111 THEJ070C SILVER SCREW (A) 8
112 RHD30236 BLACK SCREW (A) 10
113 THEC309Z BLACK SCREW (B) 4
