6
RQT0B23
Overview of controls
Do the procedures with the remote control. You can also use the buttons on the main unit if they are the same.
A Standby/on switch [`], [1]
Press to switch the unit from on to standby mode or
vice versa. In standby mode, the unit is still
consuming a small amount of power.
B Select the audio source
On the main unit:
To start Bluetooth
®
pairing, press and hold
[ –PAIRING].
C Basic playback control
D View the setup menu
E View the content information
F Select or confirm the option
G Open or close the disc tray
H Decrease the brightness of the display panel
To cancel, press the button again.
I Adjust the volume level
J Mute the sound
To cancel, press the button again.
“MUTE” is also canceled when you adjust the volume
or when you switch off the system.
K View the play menu
L Select the sound effects
M Display panel
N Remote control sensor
Distance: Within approximately 7 m (23 ft)
Angle: Approximately 20° up and down,
30° left and right
O Headphones jack ( )
Plug type: Ø 3.5 mm (
") stereo (not supplied)
– Excessive sound pressure from earphones and
headphones can cause hearing loss.
– Listening at full volume for long periods may
damage the user’s ears.
P USB port ( )
Q Disc tray
Preparing the remote control
Use alkaline or manganese battery.
Install the battery so that the poles (+ and –) align with
those in the remote control.
PC_RQT0B23-C_en.fm Page 6 Wednesday, March 16, 2016 11:27 AM
