Specifications
Model No.
80-inch model
: TH-80SF2HU
70-inch model
: TH-70SF2HU
80-inch model
: TH-80SF2HW
70-inch model
: TH-70SF2HW
Power Consumption
80-inch model
380 W
70-inch model
235 W
Power off condition
0.3 W
Stand-by condition
0.5 W
LCD Display panel
80-inch model
80-inch VA panel (Edge LED backlight), 16:9 aspect
ratio
70-inch model
70-inch VA panel (Edge LED backlight), 16:9 aspect
ratio
Screen size
80-inch model
1 771 mm (W) × 996 mm (H) × 2 032 mm (diagonal) /
69.7” (W) × 39.2” (H) × 80.0” (diagonal)
70-inch model
1 538 mm (W) × 865 mm (H) × 1 765 mm (diagonal) /
60.5” (W) × 34.0” (H) × 69.5” (diagonal)
No. of pixels
2 073 600
(1 920 (Horizontal) × 1 080 (Vertical))
Dimensions (W × H × D)
80-inch model
1 835 mm × 1 060 mm × 82 mm / 72.3” × 41.8” × 3.3”
70-inch model
1 580 mm × 919 mm × 80 mm / 62.2” × 36.2” × 3.2”
Mass
80-inch model
Approx. 62.0 / 135 lbs net
70-inch model
Approx. 45.0 / 99 lbs net
Power source
TH-80SF2HU, TH-70SF2HU:
110‒127V~(110‒127Valternatingcurrent),
50/60 Hz
TH-80SF2HW, TH-70SF2HW:
220‒240V~(220‒240Valternatingcurrent),
50/60 Hz
Operating condition
Temperature
0°C‒40°C(32°F‒104°F)
*
1
Humidity
20%‒80%(nocondensation)
Storing condition
Temperature
-20°C‒60°C(-4°F‒140°F)
Humidity
20%‒80%(nocondensation)
Connection terminals
HDMI 1
HDMI 2
TYPE A Connector
*
2
× 2
Audio signal:
Linear PCM (sampling frequencies: 48 kHz,
44.1 kHz, 32 kHz)
DVI-D IN
DVI-D 24 Pin × 1:
Compliance with DVI Revision 1.0
Compatible with HDCP 1.1
DVI-D OUT
DVI-D 24 Pin × 1:
Compliance with DVI Revision 1.0
Compatible with HDCP 1.1
AV IN
Audio/Video 4-pole mini jack (M3) × 1
(see page 22)
Video: 1.0 Vp-p (75 Ω)
Audio: Stereo mini jack (M3) × 1, 0.5 Vrms
Shared by AV IN, DVI-D IN and PC IN
