Section 2 – Cable Identification
Studio 300 Cable
11
The Studio 300 Cable connects the
Camera Adaptor AG-CA300 to the
Base Station AG-BS300.
It is available in lengths of
25, 50 or 100 Meters.
It contains a DC Power Cable and 2
SDI cables.
The Maximum Distance that
can be used is 100 Meters.
For longer lengths, a Fiber Option is
Recommended
(Explained later in this guide).
Cable Labels
Cable Labels
Part #’s
Studio300/100
Studio300/50
Studio300/25
