Section 2 – Cable Identification
Studio300 Cable
12
In order to make the BNC Connection
easier to attach to the AG-CA300, use the
2 right angle BNC adaptors supplied with
the Studio Cable.
To increase cable reliability,
please loop the studio cable
through the strain relieve and
secure with the supplied cable
strap as shown.
Panasonic Solutions Company
Strain Relieve Clamp
Cable Strap
To Next Page
