Panasonic TC-L32C22

TC-L32C22
60
12.7. V-Board
V-Board (A Side)
TNPA4834
Parts Location
12.8. V-Board
V-Board (B Side)
TNPA4834
Ref. No Location Ref. No Location
D500 B7 D504 B5
D502 A3 D505 A5
D503 B3 D506 B7
1
A
B
2 3 4 5 6 7 8 9 10
1
A
B
2 3 4 5 6 7 8 9 10
