Panasonic TC-P58S2

26
8.18. Remove the Plasma panel sec-
tion from the Cabinet assy
(glass)
1. Remove the plasma panel fastening screws (×13 ) and
remove the cabinet assy.
2. For leaving the cabinet assy from the plasma panel, pull
the bottom of the cabinet assy forward, lift, and remove.
8.19. Remove the Glass holders
1. Remove the Cabinet assy. (See section 8.18.)
2. Remove the screws (×14 , ×16 ).
3. Remove the Glass holder top rear and Glass holder bot-
tom rear.
4. Remove the screws (×8 ).
5. Remove the Glass holders (L, R).
6. Remove the Front glass.
7. Remove the Glass holder top front.
8. Remove the Glass holder bottom front.
9. Remove the screws (×2 ).
10. Remove the Rear cover hooks (L, R).
