Panasonic TGP600

29
5.1.4. XML Object Outline
The following table is an outline of main XML objects.
Element
Functionality
ppxml
Root element
Screen
Screen object is same as Window of UI.
Components
Components object is correction of UI control object mainly.
Label
It displays the text string, date-time. (*1)
PictureBox
It displays BMP format data.
TextBox
It enables the user to enter and modify the text.
Softkeys
Soft keys definition.
FFKeys
FF keys definition.
Pagekeys
Page keys definition.
Menu
It displays Menu items.
PhoneBook
It displays Network Phonebook using built in phonebook UI. (*1)
Softkeys
Soft keys definition.
FFKeys
FF keys definition.
Pagekeys
Page keys definition. (*2)
Events
Events are an object to catch events. Events can also have some
"Actions".
Timer
It is able to define timer period and actions at the expiration. (*1)
Softkeys
Soft keys definition.
FFKeys
FF keys definition.
Pagekeys
Page keys definition. (*2)
Redialkey
Redial key definition.
Trigger
It is used for the Push Service initiated from the server. (*1)
SetVariables
It provides the global variable which is available until rebooting.
Execute
Execute defines the operations (Reboot, SetXmlMode).
Note.
(*1): TGP600 supports only these elements.
(*2): HDV230/330/430 supports only these elements.
*Screen version: TGP600 - 2.0, HDV100/130/230/330/430 - 2.0/3.0
*Trigger version: TGP600 - 2.0, HDV100/130/230/330/430 - 2.0/3.0
