Panasonic TH-103PF9UK - 103" Plasma Panel - Specifi Cations

46
TH-103PF9UK
Power Source 240 V AC, 50/60 Hz (single phase)
Power Consumption
Power on 1,550 W
Stand-by condition Save OFF 1.5 W, Save ON 1.3 W
Power off condition 0.5 W
Plasma Display panel Drive method : AC type 103-inch,
16:9 aspect ratio
Screen size
89.5” (2,269 mm) (W) × 50.5” (1,277 mm) (H)
× 103.0” (2,604 mm) (diagonal)
(No.of pixels) 2,073,600 (1,920 (W) × 1,080 (H))
[5,760 × 1,080 dots]
Operating condition
Temperature 32 °F - 104 °F (0 °C - 40 °C)
Humidity 20 % - 80 %
Applicable signals
Color System NTSC, PAL, PAL60, SECAM, Modifi ed NTSC
Scanning format 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 750 (720) / 60p · 50p, 1125 (1080) / 60i · 60p · 50i · 50p
· 24p · 25p · 30p · 24sF ···· SMPTE274M, 1250 (1080) / 50i
PC signals VGA, SVGA, XGA, SXGA,
UXGA ···· (compressed)
Horizontal scanning frequency 15 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
Connection terminals
DVI-D Video Input
Audio Input
Content Protection
DVI-D 24 Pin x 1
compliance with DVI Revision 1.0
* Refer to page 12 for applicable signals
Stereo mini jack (M3) x 1
0.5Vrms
Compatible with HDCP 1.1
COMPONENT/RGB Y/G (BNC)
P
B/B (BNC), PR/R (BNC)
AUDIO IN (RCA PIN JACK × 2)
Y or G with/sync 1.0 Vp-p (75 Ω)
0.7 Vp-p (75 Ω)
0.5 Vrms
PC
(HIGH-DENSITY MINI D-SUB 15PIN)
B/P
B/CB :
R/P
R/CR :
HD/VD:
VBS(use HD port)
AUDIO IN (M3 JACK)
Y or G with/sync 1.0 Vp-p (75 Ω)
Y or G without/sync 0.7 Vp-p (75 Ω)
0.7 Vp-p (75 Ω)
0.7 Vp-p (75 Ω)
1.0 - 5.0 Vp-p (high impedance)
with/picture 1.0 Vp-p (high impedance)
without/picture 0.3 Vp-p (high impedance)
0.5 Vrms
SERIAL EXTERNAL CONTROL TERMINAL (D-SUB 9PIN) RS-232C COMPATIBLE
AUDIO OUT RCA PIN JACK × 2 (L / R)
OUTPUT LEVEL : VARIABLE (-
∞
~ 0 dB) [INPUT 1 kHz / 0 dB, 10 kΩ Load]
Accessories Supplied
Remote Control Transmitter EUR7636070R
Batteries 2 × AA Size
Fixing bands (TMME203 or TMME187) × 2
Dimensions (W × H × D)
95.0” (2,414 mm) × 56.0” (1,421 mm) × 5.0” (129 mm)
(141 mm when including protruding portion of slots)
Mass (weight) approx. 485.0 lbs
Note:
Design and specifi cations are subject to change without notice. Mass and dimensions shown are approximate.
Specifi cations
