Specifi cations
TH-37PH10UK TH-42PH10UK
Power Source 120 V AC, 50/60 Hz
Power Consumption
Power on 340 W 380 W
Stand-by condition Save OFF 0.7 W, Save ON 0.5 W Save OFF 0.7 W, Save ON 0.5 W
Power off condition 0.2 W 0.2 W
Plasma Display panel Drive method : AC type 37-inch,
16:9 aspect ratio
Drive method : AC type 42-inch,
16:9 aspect ratio
Screen size 32.2” (819 mm) (W) × 18.0” (457 mm) (H)
× 37” (938 mm) (diagonal)
36.3” (922 mm) (W) × 20.4” (518 mm) (H)
× 42” (1,057 mm) (diagonal)
(No.of pixels) 737,280 (1,024 (W) × 720 (H))
[3,072 × 720 dots]
786,432 (1,024 (W) × 768 (H))
[3,072 × 768 dots]
Operating condition
Temperature 32 °F - 104 °F (0 °C - 40 °C)
Humidity 20 % - 80 %
Applicable signals
Color System NTSC, PAL, PAL60, SECAM, Modifi ed NTSC
Scanning format 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 750 (720) / 60p · 50p, 1125 (1080) / 60i · 50i · 24p · 25p
· 30p · 24sF ···· SMPTE274M, 1250 (1080) / 50i
PC signals VGA, SVGA
XGA, SXGA, UXGA ···· (compressed)
Horizontal scanning frequency 15 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
VGA, SVGA, XGA
SXGA, UXGA ···· (compressed)
Horizontal scanning frequency 15 - 110 kHz
Vertical scanning frequency 48 - 120 Hz
Connection terminals
AV IN VIDEO IN (BNC) 1.0 Vp-p (75 Ω)
S VIDEO IN (MINI DIN 4PIN) Y: 1.0 Vp-p (75 Ω), C: 0.286 Vp-p (75 Ω)
AUDIO IN (RCA PIN JACK × 4) 0.5 Vrms (high impedance)
COMPONENT/RGB IN Y/G (BNC) with/sync 1.0 Vp-p (75 Ω)
P
B/B (BNC), PR/R (BNC) 0.7 Vp-p (75 Ω)
AUDIO IN (RCA PIN JACK × 2) 0.5 Vrms (high impedance)
PC IN (HIGH-DENSITY MINI D-SUB 15PIN) Y or G with/sync 1.0 Vp-p (75 Ω)
Y or G without/sync 0.7 Vp-p (75 Ω)
B/P
B/CB: 0.7 Vp-p (75 Ω)
R/P
R/CR: 0.7 Vp-p (75 Ω)
HD/VD: 1.0 - 5.0 Vp-p (high impedance)
AUDIO IN (M3 JACK) 0.5 Vrms (high impedance)
SERIAL EXTERNAL CONTROL TERMINAL (D-SUB 9PIN) RS-232C COMPATIBLE
SPEAKERS (6 Ω) 16W [8 W + 8 W] (10 % THD)
Accessories Supplied
Remote Control Transmitter EUR7636070R
Batteries 2 × AA Size
Fixing bands TMME203 × 2
Dimensions (W × H × D)
36.2” (920 mm) × 21.7” (550 mm) × 3.5” (89 mm) 40.2” (1,020 mm) × 24” (610 mm) × 3.5” (89 mm)
Mass (weight)
main unit only approx. 48.5 lbs approx. 57.3 lbs
with speakers approx. 57.3 lbs approx. 66.1 lbs
Note:
Design and specifi cations are subject to change without notice. Mass and dimensions shown are approximate.
