15
About Main Menu
When “WHITEBOARD function” of the display is set to “On”, selecting the WHITEBOARD input will display the main
menu of the preinstalled “Easy WhiteBoard” software. For other inputs than the WHITEBOARD input, touching the
screen with the electronic pen will display the menu.
The menu has various function buttons for changing the color and width of the marker and other controls.
005 / 005
Page Menu
Page Menu*
* Displayed only when a
USB compatible recording
medium is connected.
Close the menu
Switch the mode
Undo/Redo
Straight lineMarker
Eraser
Erase all
Color
Width
Erase selected area
Exit the application
Main menu
Page operation
menu
Menu display
tab
Display the main menu
Clicking the tab on the screen will display the menu on the side clicked.
Close the menu
Clicking “close the menu” closes the menu and displays the tab.
To display the menu again, click the tab.
Switch the mode
The software has two modes that are switched to each other by clicking when the main menu is started
from other inputs than WHITEBOARD. The characters drawn in each mode are not deleted even when the mode is
switched.
: WhiteBoard mode. An object will be drawn on the white background.
: Transparent mode. The image of each input will be displayed on the background.
When the input is switched, the drawn characters disappear once, but they will appear again when you touch the •
screen with the electronic pen.
■ Split screen display
Clicking in the WhiteBoard mode will display the submenu of split screen display, allowing you to display the image
of each input and the WhiteBoard mode screen on the split areas according to a clicked icon in the submenu.
WhiteBoard
mode screen
image of each
input
WhiteBoard mode
screen
image of each input
Clicking will return the screen to the full screen display of WhiteBoard mode.
Notes
Only the WhiteBoard mode is available in the WHITEBOARD input.•
Split screen display is not available in the WHITEBOARD input.•
