English
17
Note
●
Design and Specifications are subject to change
without notice. Mass and Dimensions shown are
approximate.
●
For information about the open source software, refer
to [eHELP] (Support > Licence).
■ When using the wall-hanging bracket
●
Choosing to wall mount the TV shall be done at
the owner’s risk. Always use a qualified installer to
perform a TV wall bracket installation. Incorrect fitting
may cause equipment to fall, resulting in injury and
product damage. Any such damage will void your
warranty.
Holes for wall-hanging bracket installation
Rear of the TV
a
b
a: 400 mm
b: 400 mm
(View from the side)
Depth of screw
55-inch model
minimum: 10 mm
maximum: 16 mm
60-inch model
minimum: 9 mm
maximum: 17 mm
65-inch model
minimum: 11 mm
maximum: 19 mm
Type of screw: M6
Screw for fixing the TV onto the
wall-hanging bracket (not supplied with
the TV)
Receiving systems / Band name
Satellite TV
New Zealand
Digital satellite services
Receiver frequency range - 950 MHz to 2150 MHz
DiSEqC - Version 1.0
Digital TV
Australia
7 MHz VHF / UHF (Australia) free-to-air TV
broadcast reception
New Zealand
8 MHz VHF / UHF (New Zealand) free-to-air TV
broadcast reception
PAL B / G
Reception of Off air broadcast
PAL 60 Hz
Playback of NTSC tape from some PAL Video
recorders (VCR)
M.NTSC
Playback from M.NTSC Video recorders (VCR)
NTSC
Playback from NTSC Video recorders (VCR)
Satellite dish input
New Zealand
Female F-type 75 Ω
Aerial input
Standard Belling & Lee connector
VHF / UHF
Operating conditions
Temperature
0 °C - 35 °C
Humidity
20 % - 80 % RH (non-condensing)
Built-in wireless LAN
Standard compliance and Frequency range
*
IEEE802.11a/n
5.15 GHz - 5.35 GHz, 5.47 GHz - 5.85 GHz
IEEE802.11b/g/n
2.400 GHz - 2.4835 GHz
Security
WPA2-PSK (TKIP/AES)
WPA-PSK (TKIP/AES)
WEP (64 bit/128 bit)
*
:
The frequency and channel differ depending on the
country.
