Panasonic TH-86SQ1W - Preset Signals

138
English
Preset Signals
This unit can display the video signals shown in the table below.
●
The contents of HDMI signal in the Plug and Play-supported signal column are as follows.
EDID1: 4K/60p (HDR), EDID2: 4K/60p (SDR), EDID3: 4K/30p, EDID4: 2K
Corresponding
signal
Resolution
(Dot)
Scanning
frequency
Dot clock
frequency
(MHz)
Format
*
2
Plug and Play-supported signal
*
5
Horizontal
(kHz)
Vertical
(Hz)
HDMI
DL DP
DVI-D/
PC
EDID
1
EDID
2
EDID
3
EDID
4
480/60i 720 x 480i 15.73 59.94 13.50 Y
480/60i
720 (1 440) x
480i
*
1
15.73 59.94 27.00 D/H/DL ○ ○ ○ ○ ○
576/50i
720 (1 440) x
576i
*
1
15.63 50.00 27.00 D/H/DL ○ ○ ○ ○ ○
480/60p 720 x 483 31.47 59.94 27.00 Y/D/H/DL/DP ○ ○ ○ ○ ○ ○
576/50p 720 x 576 31.25 50.00 27.00 Y/D/H/DL/DP ○ ○ ○ ○ ○ ○
720/60p 1 280 x 720 45.00 60.00 74.25 Y/D/H/DL/DP ○ ○ ○ ○ ○ ○
720/50p 1 280 x 720 37.50 50.00 74.25 Y/D/H/DL/DP ○ ○ ○ ○ ○ ○
1080/60i 1 920 x 1 080i 33.75 60.00 74.25 Y/D/H/DL/DP ○ ○ ○ ○ ○ ○
1080/50i 1 920 x 1 080i 28.13 50.00 74.25 Y/D/H/DL/DP ○ ○ ○ ○ ○ ○
1080/24p 1 920 x 1 080 27.00 24.00 74.25 Y/D/H/DL/DP ○ ○ ○ ○ ○ ○
1080/24PsF 1 920 x 1 080i 27.00 48.00 74.25 D/H/DL/DP
1080/25p 1 920 x 1 080 28.13 25.00 74.25 Y/D/H/DL/DP ○ ○ ○ ○ ○ ○
1080/30p 1 920 x 1 080 33.75 30.00 74.25 Y/D/H/DL/DP ○ ○ ○ ○ ○ ○
1080/60p 1 920 x 1 080 67.50 60.00 148.50 Y/D/H/DL/DP ○ ○ ○ ○ ○ ○
1080/50p 1 920 x 1 080 56.25 50.00 148.50 Y/D/H/DL/DP ○ ○ ○ ○ ○ ○
2K/24p 2 048 x 1 080 27.00 24.00 74.25 D/H/DL/DP
2K/25p 2 048 x 1 080 28.13 25.00 74.25 D/H/DL/DP
2K/30p 2 048 x 1 080 33.75 30.00 74.25 D/H/DL/DP
2K/48p 2 048 x 1 080 54.00 48.00 148.50 D/H/DL/DP
2K/60p 2 048 x 1 080 67.50 60.00 148.50 D/H/DL/DP
2K/50p 2 048 x 1 080 56.25 50.00 148.50 D/H/DL/DP
3840 x 2160/24p 3 840 x 2 160 54.00 24.00 297.00 H/DL/DP ○ ○ ○ ○ ○
3840 x 2160/25p 3 840 x 2 160 56.25 25.00 297.00 H/DL/DP ○ ○ ○ ○ ○
3840 x 2160/30p 3 840 x 2 160 67.50 30.00 297.00 H/DL/DP ○ ○ ○ ○ ○
3840 x 2160/60p 3 840 x 2 160 135.00 60.00 594.00 H/DL
*
4
/DP ○ ○ ○
3840 x 2160/50p 3 840 x 2 160 112.50 50.00 594.00 H/DL
*
4
/DP ○ ○ ○
4096 x 2160/24p 4 096 x 2 160 54.00 24.00 297.00 H/DL/DP ○ ○ ○ ○ ○
4096 x 2160/25p 4 096 x 2 160 56.25 25.00 297.00 H/DL/DP ○ ○ ○ ○ ○
4096 x 2160/30p 4 096 x 2 160 67.50 30.00 297.00 H/DL/DP ○ ○ ○ ○ ○
4096 x 2160/60p 4 096 x 2 160 135.00 60.00 594.00 H/DL
*
4
/DP ○ ○ ○
4096 x 2160/50p 4 096 x 2 160 112.50 50.00 594.00 H/DL
*
4
/DP ○ ○ ○
640 x 400/70 640 x 400 31.47 70.09 25.18 R/D/H/DL/DP
640 x 400/85 640 x 400 37.86 85.08 31.50 R/D/H/DL/DP
640 x 480/60 640 x 480 31.47 59.94 25.18 R/D/H/DL/DP ○ ○ ○ ○ ○ ○ ○
640 x 480/67 640 x 480 35.00 66.67 30.24
R/D/H/DL/DP
640 x 480/73 640 x 480 37.86 72.81 31.50 R/D/H/DL/DP
640 x 480/75 640 x 480 37.50 75.00 31.50 R/D/H/DL/DP
640 x 480/85 640 x 480 43.27 85.01 36.00 R/D/H/DL/DP
800 x 600/56 800 x 600 35.16 56.25 36.00 R/D/H/DL/DP
800 x 600/60 800 x 600 37.88 60.32 40.00 R/D/H/DL/DP ○ ○ ○ ○ ○ ○ ○
