Panasonic TH-L32X10A

Ref. No. Part No. Part Name &
Description
Remarks
R3222 ERJ2GE0R00X M 0 OHM 1/4W
R3224 ERJ2GE0R00X M 0 OHM 1/4W
R3231 ERJ2GE0R00X M 0 OHM 1/4W
R3233 ERJ2GE0R00X M 0 OHM 1/4W
R3235 ERJ2GE0R00X M 0 OHM 1/4W
R4218 ERJ2GE0R00X M 0 OHM 1/4W
R4539 ERJ2GE0R00X M 0 OHM 1/4W
R4541 ERJ2GE0R00X M 0 OHM 1/4W
R4542 ERJ2GE0R00X M 0 OHM 1/4W
R4543 ERJ2GE0R00X M 0 OHM 1/4W
R4604 ERJ2GE0R00X M 0 OHM 1/4W
R4607 ERJ2GE0R00X M 0 OHM 1/4W
R4613 ERJ2GE0R00X M 0 OHM 1/4W
R4614 ERJ2GE0R00X M 0 OHM 1/4W
R4615 ERJ2GE0R00X M 0 OHM 1/4W
R4616 ERJ2GE0R00X M 0 OHM 1/4W
R4623 ERJ2GE0R00X M 0 OHM 1/4W
R4742 ERJ2GE0R00X M 0 OHM 1/4W
R4743 ERJ2GE0R00X M 0 OHM 1/4W
R5443 ERJ6GEY0R00V M 0 OHM J 1/10W
R5449 ERJ2GE0R00X M 0 OHM 1/4W
R5474 ERJ2GE0R00X M 0 OHM 1/4W
R5479 ERJ2GE0R00X M 0 OHM 1/4W
R5498 ERJ2GE0R00X M 0 OHM 1/4W
R7800 ERJ6GEY0R00V M 0 OHM J 1/10W
R7898 ERJ6GEY0R00V M 0 OHM J 1/10W
R8007 D0GBR00Z0002 M 0 OHM J 1/16W
R8026 ERJ2GE0R00X M 0 OHM 1/4W
R8027 ERJ2GE0R00X M 0 OHM 1/4W
R8303 ERJ2GE0R00X M 0 OHM 1/4W
R8304 ERJ2GE0R00X M 0 OHM 1/4W
R8306 ERJ2GE0R00X M 0 OHM 1/4W
R8307 ERJ2GE0R00X M 0 OHM 1/4W
R8310 ERJ2GE0R00X M 0 OHM 1/4W
R8311 ERJ2GE0R00X M 0 OHM 1/4W
R8314 ERJ2GE0R00X M 0 OHM 1/4W
R8315 ERJ2GE0R00X M 0 OHM 1/4W
R8316 ERJ2GE0R00X M 0 OHM 1/4W
R8317 ERJ2GE0R00X M 0 OHM 1/4W
R8319 ERJ2GE0R00X M 0 OHM 1/4W
R8356 ERJ2GE0R00X M 0 OHM 1/4W
R8392 ERJ2GE0R00X M 0 OHM 1/4W
R8484 ERJ2GE0R00X M 0 OHM 1/4W
R8485 ERJ2GE0R00X M 0 OHM 1/4W
R8486 ERJ2GE0R00X M 0 OHM 1/4W
R8497 ERJ2GE0R00X M 0 OHM 1/4W
R8644 ERJ2GE0R00X M 0 OHM 1/4W
R8660 ERJ2GE0R00X M 0 OHM 1/4W
R8802 ERJ2GE0R00X M 0 OHM 1/4W
JS1003 ERJ2GE0R00X M 0 OHM 1/4W
JS2502 ERJ2GE0R00X M 0 OHM 1/4W
18.2.6. Capacitor
Ref. No. Part No. Part Name &
Description
Remarks
C0941 F1G1H680A731 E 68PF J 50V
C0942 F1G1H330A731 C 33PF J 50V
C1003 F1G1H102A730 E 1000PF K 50V
C1028 F1G1H102A730 E 1000PF K 50V
C1030 F1G1H102A730 E 1000PF K 50V
Ref. No. Part No. Part Name &
Description
Remarks
C1040 F1G1H102A730 E 1000PF K 50V
C1041 F1G1H102A730 E 1000PF K 50V
C1043 F1G1H102A730 E 1000PF K 50V
C1044 F1G1H102A730 E 1000PF K 50V
C1045 F1G1H102A730 E 1000PF K 50V
C1050 F1G1H102A730 E 1000PF K 50V
C1051 F1G1H102A730 E 1000PF K 50V
C1053 F1G1H102A730 E 1000PF K 50V
C1102 F1J1A106A043 C 10UF
C1103 F1G1C104A116 E 0.1UF K 16V
C1104 F1G1C104A116 E 0.1UF K 16V
C1105 F1H1A1050032 E 1UF K 10V
C1106 F1H1H330A971 C 33PF J 50V
C1107 F1G1H220A731 E 22PF J 50V
C1108 F1G1C104A116 E 0.1UF K 16V
C1109 F1H1A1050032 E 1UF K 10V
C1111 F1H1A1050032 E 1UF K 10V
C1112 F1G1C104A116 E 0.1UF K 16V
C1114 F1G1C104A116 E 0.1UF K 16V
C1117 F1G1C104A116 E 0.1UF K 16V
C1122 F1G1E103A123 E 0.01UF K 25V
C1123 F1H1A1050032 E 1UF K 10V
C2023 F1G1C104A116 E 0.1UF K 16V
C2049 F1G1C104A116 E 0.1UF K 16V
C2050 F1G1C104A116 E 0.1UF K 16V
C2055 F1G1H120A731 E 12PF J 50V
C2056 F1G1H180A731 E 18PF J 50V
C2058 F1G1C104A116 E 0.1UF K 16V
C2059 F1J1A106A043 C 10UF
C2091 F1G1H470A731 C 47PF J 50V
C2092 F1G1H220A731 E 22PF J 50V
C2096 F1G1C104A116 E 0.1UF K 16V
C2098 EEEHB0J221UP E 220UF 6.3V
C2099 EEEHB0J221UP E 220UF 6.3V
C2102 F1G1C104A116 E 0.1UF K 16V
C2105 F1G1C104A116 E 0.1UF K 16V
C2106 F1G1C104A116 E 0.1UF K 16V
C2107 F1J1A106A043 C 10UF
C2108 F1J1A106A043 C 10UF
C2109 F1G1C104A116 E 0.1UF K 16V
C2110 F1G1C104A116 E 0.1UF K 16V
C2111 F1J1A475A039 P 4.7UF 10V
C2112 F1J1A106A043 C 10UF
C2113 F1J1A106A043 C 10UF
C2114 F1G1C104A116 E 0.1UF K 16V
C2115 F1G1C104A116 E 0.1UF K 16V
C2117 F1G1C104A116 E 0.1UF K 16V
C2118 F1J1A475A039 P 4.7UF 10V
C2120 F1G1H560A731 C 56PF J 50V
C2121 F1G1H560A731 C 56PF J 50V
C2122 F1G1C103A116 C 0.01UF K 16V
C2123 F1G1C103A116 C 0.01UF K 16V
C2124 F1G1C104A116 E 0.1UF K 16V
C2125 F1G1C103A116 C 0.01UF K 16V
C2127 F1G1C103A116 C 0.01UF K 16V
C2128 F1G1C103A116 C 0.01UF K 16V
C2129 F1G1C103A116 C 0.01UF K 16V
C2135 F1G1C103A116 C 0.01UF K 16V
C2136 F1G1C103A116 C 0.01UF K 16V
C2137 F1J1A106A043 C 10UF
