108
USB Devices
To connect the device
1 Connect the USB device to one of the USB 2.0 ports (A) and USB 3.0 port (B).
The USB 3.0 port (B) supports USB 3.0.
For further information, refer to the instruction manual of the USB device.
To remove the device
1 Disable the USB device.
A Click on the notification area and then click .
B Select the USB device.
A Double-click on the notification area and select the USB device.
Follow the on-screen instructions.
These steps are not necessary when;
• Removing the device after turning off the computer.
• is not displayed.
• The device does not appear in the list in step A.
2 Remove the USB device.
Connecting/Removing USB Devices
BA
<CF-C1 Series> <CF-S10 Series>
Windows 7
Windows XP
To Next Page
