Panasonic TX-32LXD80F - Setting Inspection

Setting Inspection
Voltage Confirmation
Confirm the following voltages:
A board
Description Test point Normal mode
SUB 1,8V TP5602 1,76V – 1,85V
SUB 1,2V TP5601 1,22V – 1,27V
SUB 3,3V TP5600 3,19V – 3,39V
SUB5V TP1011 4,75V – 5,25V
DVDDIO3,3V/
TVDD3,3V
TP4531 3,23V – 3,37V
BT30V TP2905 29,5V – 31,5V
DVDD1,8V TP4529 1,77V – 1,83V
AUD3,3V TP2031 3,23V – 3,37V
DVDD1,8V TP2032 1,77V – 1,83V
5V TP2030 4,75V – 5,25V
STB 3,3V TP7601 3,23V – 3,37V
SUB9V TP002 8,75V – 9,25V
LVDS12V TP001 11,65V – 12,35V
