Panasonic TX-32LXD80F - Replacement Parts List

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type number to your order.
Replacement Parts List
Important Safety Notice
The marking (RTL) indicates that the Retention Time is Limited for this item. After the
discontinuation of this assembly in production, the item will continue to be available for
a specific period of time. The retention period of availability is dependent on the type of
assembly, and in accordance with the laws governing part and product retention. After
the end of this period, the assembly will no longer be available.
RTL (Retention Time Limited)
Note:
X
The marking (X) indicates that board should be exchanged for service.
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
EXPLODED VIEW
SPEAKER 1 EAS16S09A
TUNER 2 ENG37E09KF
CONTROL PANEL 3 K0RB00500028
LCD PANEL 4 L5EDD8Q00042
POWER UNIT 5 N0AC3GJ00015
REMOTE CONTROL 6 N2QAYB000239
CI COVER LABEL 7 TBM0E1467
POWER BUTTON 8 TBX0E84500
CONNECTOR COVER 9 TKP0E16001
HDMI/SD BRACKET 10 TKP0E30501
POWER BUTTON BRACKET 11 TKP0E30701
REAR AV BRACKET 12 TKP0E30801
TRIM PANEL 13 TKP0E90601
BACK COVER 14 TKU0E1701
LCD BRACKET 15 TKZ0E9164
VESA METAL 16 TKZ0E9575
G P.C.B. 17 TNP8EGL91AA
K P.C.B. 18 TNP8EKL92AA
V P.C.B. 19 TNP8EVL91AA
PEDESTAL ASSY 20 TTX0E0016
L CHASSIS FRAME BRACKE 21 TUA0E2300-1
R CHASSIS FRAME BRACKE 22 TUA0E4800
MISCELLANEOUS COMPONENTS
BATTERY . R6RCOD/2P
SIDE AV LABEL . TBM0E1204
REAR AV LABEL . TBM0E9002
CI/SD LABEL . TBM0E9003
HDMI/SIDE LABEL . TBM0E9005
SCREW . THTF012J
IR/LED PANEL . TKP0E30301
FELT . TMK0E089
FELT . TMK0E090
TAB-RELEASE CABLE. TMM8E18048
CLEANING CLOTH . TPEX020
SHIELD CASE . TUC0EC5007
SCREW . XTB4+15JFJK
SCREW . XTS3+8JFJ
SCREW . XTV3+10JFJK
SCREW . XTW3+12TFJ
SCREW . XYN4+C12FJ
SCREW . XYN4+F10FJ
BOTTOM CUSHION BOTCUS TPD0E2020
CARTON CARTON TPC0E48800
EDGE SADDLE CK315 TMME075
EDGE SADDLE CK316 TMME075
FERRITE CORE FC03 J0KG00000100
TOP CUSHION TOPCUS TPD0E1047
I.C.s
IC IC1000 C1ZBZ0003577
MICRO_GENX5 IC1100 MN103SG3FPA1
EEPROM GENX IC1101 24GLP23GENX
RESET IC IC1104 C0EBM0000026
REGULATOR IC2008 C0CBCBE00001
AUDIO AMPLIFIER IC2012 C1BB00000947
REGULATOR IC2013 C0DBGYY00281
AUDIO PROCESSOR IC2106 C1AB00002909
1.8V REGULATOR IC2107 C0DBFFD00003
AUDIO AMPLIFIER IC2301 C1AB00002875
REGULATOR IC2902 C0DBGYY00281
AUDIO VIDEO SWITCHIC3001 C1AB00002855
AD VIDEO DECODER IC4510 C1AB00002966
REGULATOR IC4511 C0CBCBE00001
REGULATOR IC4512 C0DBGYY00477
REGULATOR IC4513 C0DBGYY00477
IC SWITCH IC4514 C0JBAZ002301
IC SWITCH IC4515 C0JBAZ002301
EEPROM EDID IC4700 24GLP23EDID3
DC/DC CONVERTER IC5600 C0DBAYY00273
DC/DC CONVERTER IC5601 C0DBAYY00274
REGULATOR IC5602 C0DBEYY00083
REGULATOR IC5603 C0DBAJB00004
IC OVP IC5604 C1ZBZ0003725
RESET IC IC5660 C0EBM0000026
REGULATOR IC5751 C0DBAZH00029
REGULATOR IC5752 C0DBAZH00029
PEAKS LITE 2 IC8001 MN2WS0047
DDR SDRAM IC8002 C3ABRY000015
DDR SDRAM IC8003 C3ABRY000015
CLOCK GENERATOR IC8004 C0ZBZ0001567
COFDM DEMODULATORIC8301 C1AB00002710
REGULATOR IC8302 C0DBGFD00004
LEVEL SHIFTER IC8401 C1AB00002913
IC SWITCH IC8403 C0ZBZ0001584
BUS BUFFER IC8404 C0JBAZ002692
BUS BUFFER IC8405 C0JBAZ002692
BUFFER IC8408 C0JBAU000025
BUFFER IC8409 C0JBAU000025
FLASH MEMORY IC8554 TVR0E001-4
LED RECEIVER RM2501 PNA4701M05TV
PHOTO IC DIODE SN2551 B3JB00000046
