Panasonic TX-32LXD80F - Page 34

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CAPC2174 F1H1A1050032 10V 1000nF
ELECTC2175 F2G1C470A022 16V 47µF
S.M.CAPC2176 F1H1H103A970 50V 10nF
ELECTC2179 F2G1C470A022 16V 47µF
S.M.CAPC2180 F1H1A1050032 10V 1000nF
CERAMICC2184 F1H1H102A219 50V 1nF
S.M.CAPC2186 ECJ1VB1H104 50V 100nF
CERAMICC2187 F1H0J2250008 6.3V 2200nF
S.M.CAPC2188 F1H1H471A971 50V 470pF
S.M.CAPC2189 F1H1A1050032 10V 1000nF
S.M.CAPC2190 F1J1A106A043 10V 10µF
S.M.CAPC2191 F1J1A106A043 10V 10µF
ELECTC2192 F2G0J470A019 6.3V 47µF
CERAMICC2195 F1H1H102A219 50V 1nF
S.M.CAPC2197 F1H1E333A129 25V 33nF
S.M.CAPC2198 F1H1E333A129 25V 33nF
CERAMICC2202 F1H0J2250008 6.3V 2200nF
S.M.CAPC2203 F1H1A1050032 10V 1000nF
SMDC2204 ECJ1VB1C105K 16V 1000nF
ELECTC2207 F2G1C470A022 16V 47µF
CERAMICC2213 F1H1H102A219 50V 1nF
S.M.CAPC2216 ECJ1VB1H104 50V 100nF
S.M.CAPC2244 ECJ1VB1H104 50V 100nF
CERAMICC2245 F1H1H102A219 50V 1nF
S.M.CAPC2246 F1J1A106A043 10V 10µF
S.M.CAPC2251 F1J1A106A043 10V 10µF
S.M.CAPC2261 F1J1A106A043 10V 10µF
S.M.CAPC2262 F1J1A106A043 10V 10µF
S.M.CAPC2263 F1J1A106A043 10V 10µF
S.M.CAPC2264 F1J1A106A043 10V 10µF
S.M.CAPC2270 F1H1H471A971 50V 470pF
S.M.CAPC2271 F1H1H471A971 50V 470pF
S.M.CAPC2282 F1G1A473A053 10V 47nF
S.M.CAPC2301 F1G1C104A116 16V 100nF
S.M.CAPC2302 F1G1C104A116 16V 100nF
S.M.CAPC2303 F1J1E105A171 25V 1µF
S.M.CAPC2305 F1J1E105A171 25V 1µF
S.M.CAPC2307 F1J1E105A171 25V 1µF
S.M.CAPC2309 F1J1E105A171 25V 1µF
CERAMICC2310 F1H1H102A219 50V 1nF
CERAMICC2311 F1H1H102A219 50V 1nF
S.M.CAPC2313 F1H1A1050032 10V 1000nF
S.M.CAPC2317 ECJ1VB1H104 50V 100nF
S.M.CAPC2319 ECJ1VB1H104 50V 100nF
S.M.CAPC2321 ECJ1VB1H104 50V 100nF
S.M.CAPC2323 ECJ1VB1H104 50V 100nF
S.M.CAPC2333 F1J1E3340003 25V 330nF
S.M.CAPC2335 F1J1E3340003 25V 330nF
S.M.CAPC2337 F1H1H223A970 50V 22nF
S.M.CAPC2339 F1H1H223A970 50V 22nF
S.M.CAP
C2341 F1J1E3340003 25V 330nF
S.M.CAPC2343 F1J1E3340003 25V 330nF
S.M.CAPC2345 F1H1H223A970 50V
22nF
S.M.CAPC2347 F1H1H223A970 50V 22nF
S.M.CAPC2353 ECJ1VB1H104 50V 100nF
S.M.CAPC2359 ECJ1VB1H104 50V 100nF
ELECTC2361 EEEFG1E471P 25V 470µF
ELECTC2364 EEEFG1E471P 25V 470µF
ELECTC2365 EEEFG1E471P 25V 470µF
S.M.CAPC2375 F1H1H223A970 50V 22nF
S.M.CAPC2377 F1H1H223A970 50V 22nF
S.M.CAPC2379 F1H1H223A970 50V 22nF
S.M.CAPC2381 F1H1H223A970 50V 22nF
S.M.CAPC2383 F1G1H102A730 50V 1nF
S.M.CAPC2385 F1G1H102A730 50V 1nF
S.M.CAPC2387 F1G1H102A730 50V 1nF
S.M.CAPC2389 F1G1H102A730 50V 1nF
ELECC2404 F2G1H100A031 50V 10µF
ELECTC2406 F2G1E330A021 25V 33µF
S.M.CAPC2511 ECJ1VB1H104 50V 100nF
ELECTC2514 F2G0J470A019 6.3V 47µF
S.M.CAPC2515 F1J1H103A834 50V 10nF
S.M.CAPC2551 F1K1C105A023 16V 1000nF
ELECTC2552 F2G0J220A019 6.3V 22µF
S.M.CAPC2902 F1H1H222A970 50V 2.2nF
S.M.CAPC2906 F1H1C104A143 16V 100nF
S.M.CAPC2907 F1H1C104A143 16V 100nF
S.M.CAPC2908 F1G1C104A081 16V 100nF
S.M.CAPC2909 F1H1A1050032 10V 1000nF
ELECTC2912 F2G0J101A019 6.3V 100µF
S.M.CAPC2914 ECJ1VB1H104 50V 100nF
ELECC2915 F2G1H100A031 50V 10µF
S.M.CAPC2916 F1H1C104A143 16V 100nF
S.M.CAPC2920 F1H1H103A970 50V 10nF
S.M.CAPC2922 F1H1C104A143 16V 100nF
S.M.CAPC2923 ECJ1VB1H104 50V 100nF
S.M.CAPC2933 F1G1H102A730 50V 1nF
S.M.CAPC3002 F1H1H561A971 50V 560pF
S.M.CAPC3003 F1H1H561A971 50V 560pF
S.M.CAPC3004 F1H1H561A971 50V 560pF
S.M.CAPC3005 F1H1H561A971 50V 560pF
S.M.CAPC3007 F1H1H561A971 50V 560pF
S.M.CAPC3008 F1H1H561A971 50V 560pF
S.M.CAPC3009 F1H1H561A971 50V 560pF
S.M.CAPC3010 F1H1H561A971 50V 560pF
S.M.CAPC3011 F1H1H561A971 50V 560pF
S.M.CAPC3012 F1H1H561A971 50V 560pF
S.M.CAPC3013 F1H1H561A971 50V 560pF
S.M.CAPC3014 F1H1H561A971 50V 560pF
S.M.CAPC3018 F1J1A106A043 10V 10µF
S.M.CAPC3019 F1J1A106A043 10V 10µF
S.M.CAPC3020
F1J1A106A043 10V 10µF
S.M.CAPC3021 F1J1A106A043 10V
10µF
S.M.CAPC3022 F1H1A1050032 10V 1000nF
S.M.CAPC3024 F1H1A1050032 10V 1000nF
S.M.CAPC3025 F1H1A1050032 10V 1000nF
S.M.CAPC3026 F1H1A1050032 10V 1000nF
S.M.CAPC3027 F1J1A106A043 10V 10µF
S.M.CAPC3028 F1J1A106A043 10V 10µF
S.M.CAPC3029 F1J1A106A043 10V 10µF
S.M.CAPC3030 F1J1A106A043 10V 10µF
S.M.CAPC3039 F1H1A1050032 10V 1000nF
S.M.CAPC3041 F1H1A1050032 10V 1000nF
S.M.CAPC3043 F1H1A1050032 10V 1000nF
S.M.CAPC3044 F1H1A1050032 10V 1000nF
S.M.CAPC3046 F1H1A1050032 10V 1000nF
S.M.CAPC3047 F1H1A1050032 10V 1000nF
S.M.CAPC3048 F1H1A1050032 10V 1000nF
S.M.CAPC3049 F1H1A1050032 10V 1000nF
CERAMICC3064 F1H1H102A219 50V 1nF
CERAMICC3065 F1H1H102A219 50V 1nF
S.M.CAPC3070 F1H1A1050032 10V 1000nF
S.M.CAPC3071 F1H1A1050032 10V 1000nF
S.M.CAPC3072 ECJ1VB1H104 50V 100nF
S.M.CAPC3073 F1H1A1050032 10V 1000nF
S.M.CAPC3074 F1H1A1050032 10V 1000nF
S.M.CAPC3075 F1H1A1050032 10V 1000nF
S.M.CAPC3077 ECJ1VB1H104 50V 100nF
S.M.CAPC3083 F1H1A1050032 10V 1000nF
S.M.CAPC3084 F1H1A1050032 10V 1000nF
S.M.CAPC3085 F1H1A1050032 10V 1000nF
S.M.CAPC3086 F1H1A1050032 10V 1000nF
S.M.CAPC3087 F1H1A1050032 10V 1000nF
S.M.CAPC3088 F1H1A1050032 10V 1000nF
S.M.CAPC3089 F1H1A1050032 10V 1000nF
S.M.CAPC3090 F1H1A1050032 10V 1000nF
34
