Panasonic TX-32LXD80F - Page 37

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CAPC8091 F1H1C103A143 16V 10nF
S.M.CAPC8092 F1H1C103A143 16V 10nF
S.M.CAPC8093 F1H1C103A143 16V 10nF
S.M.CAPC8094 F1H1C103A143 16V 10nF
S.M.CAPC8095 F1H1C103A143 16V 10nF
S.M.CAPC8306 F1G1H102A730 50V 1nF
S.M.CAPC8307 F1G1C104A116 16V 100nF
S.M.CAPC8309 F1G1C104A116 16V 100nF
ELECTC8310 F2G0G101A007 4V 100µF
S.M.CAPC8311 F1G1H180A731 50V 18pF
S.M.CAPC8312 F1G1H120A731 50V 12pF
S.M.CAPC8313 F1G1E103A123 25V 10nF
S.M.CAPC8314 F1G1E103A123 25V 10nF
S.M.CAPC8319 F1G1E103A123 25V 10nF
S.M.CAPC8320 F1G1E103A123 25V 10nF
S.M.CAPC8321 F1G1E103A123 25V 10nF
S.M.CAPC8327 F1H1A1050032 10V 1000nF
S.M.CAPC8328 F1H1A1050032 10V 1000nF
S.M.CAPC8329 F1G1E103A123 25V 10nF
S.M.CAPC8330 F1G1E103A123 25V 10nF
S.M.CAPC8331 F1G1E103A123 25V 10nF
S.M.CAPC8332 F1G1E103A123 25V 10nF
S.M.CAPC8333 F1G1E103A123 25V 10nF
S.M.CAPC8334 F1G1E103A123 25V 10nF
S.M.CAPC8335 F1G1E103A123 25V 10nF
S.M.CAPC8336 F1G1E103A123 25V 10nF
S.M.CAPC8338 F1G1H220A731 50V 22pF
S.M.CAPC8339 F1G1H220A731 50V 22pF
S.M.CAPC8340 F1G1E103A123 25V 10nF
S.M.CAPC8343 F1G1C104A116 16V 100nF
S.M.CAPC8344 F1G1C104A116 16V 100nF
S.M.CAPC8345 F1G1C104A116 16V 100nF
S.M.CAPC8346 F1G1C104A116 16V 100nF
S.M.CAPC8405 F1G1C104A116 16V 100nF
S.M.CAPC8408 F1G1C104A116 16V 100nF
S.M.CAPC8409 F1G1C104A116 16V 100nF
S.M.CAPC8410 F1G1C104A116 16V 100nF
ELECTC8411 F2G1A101A019 10V 100µF
S.M.CAPC8412 F1G1C104A116 16V 100nF
S.M.CAPC8413 F1G1C104A116 16V 100nF
S.M.CAPC8414 F1G1C104A116 16V 100nF
S.M.CAPC8416 F1G1E103A123 25V 10nF
S.M.CAPC8417 F1G1E103A123 25V 10nF
S.M.CAPC8555 F1G1C104A116 16V 100nF
S.M.CAPC8601 F1G1C104A116 16V 100nF
SMDC8812 F1G1A104A012 10V 100nF
ELECTC8813 F2G1C470A022 16V 47µF
S.M.CAPC8814 F1G1C1030008 16V 10nF
S.M.CAPC8815 F1J0G2260001 4V 22µF
TERMINALS AND LINKS
8P CONNECTOR A1 K1KA08A00506
A1-V1 WIRE A1-V1 TXJA1NXA
30P CONNECTOR A5 K1KB30B00044
LVDS WIRE A5-PAN TXJA5NJA
23P CONNECTOR A7 K1KY23AA0607
2P CONNECTOR A10 K1KA02A00787
4P CONNECTOR A12 K1KA04AA0714
A12-K1 WIRE A12-K1 TXJA12NXA
6P CONNECTOR A13 K1KA06AA0104
5P CONNECTOR A14 K1KA05AA0714
A14-SPK WIRE A14-SPK TXJA14NXA-4
15P CONNECTOR A51 K1KA15A00148
A51-G51 WIRE A51-G51 TXJA51NUA-2
8P CONNECTOR CN0100 K1KA08AA0714
CN101-A13/P3 WIRECN-A, TXJP5NXA-1
15P CONNECTOR G51 K1KA15AA0194
PC TERMINAL JK3001 K1FB315A0006
SCART SOCKET JK3002B K1FY121A0004
SCART SOCKET JK3003B K1FY121A0004
YUV TERMINAL_ AUD I/OJK3100A K2HA7YYA0001
AV3 TERMINAL JK3700 K4AK30B00001
HDMI TERMINAL JK4500 K1FY119D0003
HDMI TERMINAL JK4501 K1FY119D0003
HDMI TERMINAL JK4700 K1FA119E0013
CI SLOT JK8401 K1NA68B00050
SD SLOT JK8801 K1NA09E00080
4P CONNECTOR K1 K1KA04BA0061
8P CONNECTOR V1 K1KA08B00270
SWITCHES
SWITCH SW2501 K0F162B00002
DIFFERENCES FOR MODEL TX--32LXD80
EXPLODED VIEW
A P.C.B. 23 A-32LXD80
AC CORD ASSY 24 TXASX01NJA-1
CABINET ASSY 25 TTY0E0258
MODEL LABEL 26 TBM0E1191
MISCELLANEOUS COMPONENTS
HDMI/REAR LABEL . TBM0E1463
INSTRUCTION BOOKS
ENGLISH . TQB0E0553
I.C.s
EEPROM PL2 IC8601 X24C32LXD80
DIFFERENCES FOR MODEL TX--32LXD80F
EXPLODED VIEW
A P.C.B. 23 A-32LXD80F
AC CORD ASSY 24 TXASX01NXA-1
CABINET ASSY 25 TTY0E0285
MODEL LABEL 26 TBM0E1194
MISCELLANEOUS COMPONENTS
HDMI/REAR LABEL . TBM0E9007
INSTRUCTION BOOKS
GERMAN . TQB0E0556A
DUTCH . TQB0E0556B
ITALIAN . TQB0E0556C
FRENCH . TQB0E0556D
SPANISH . TQB0E0556E
SWEDISH . TQB0E0556F
NORWEGIAN . TQB0E0556G
FINNISH . TQB0E0556H
LITHUANIAN . TQB0E0556I
PORTUGUESE . TQB0E0556J
DANISH . TQB0E0556K
BULGARIAN . TQB0E0556M
ROMANIAN . TQB0E0556N
LATVIAN . TQB0E0556O
POLISH . TQB0E0556P
HUNGARIAN . TQB0E0556Q
CZECH . TQB0E0556R
GREEK . TQB0E0556S
TURKISH . TQB0E0556T
ENGLISH . TQB0E0556U
CROATIAN . TQB0E0556V
SLOVAKIAN . TQB0E0556W
CD ROM . TQB0E0556X
ESTONIAN . TQB0E0556Z
I.C.s
EEPROM PL2 IC8601 X24C32LXD80F
