Panasonic TX-32PB50 - Page 34

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
CERAMICC3301 ECJ2VF1C104Z 16V
100nF
CERAMICC3302 ECJ2VF1C104Z 16V
100nF
CERAMICC3303 ECJ2VF1C104Z 16V
100nF
CERAMICC3322 ECJ2VC1H471J 50V
470pF
ELECTC3323 ECA1HHG100B 50V
10µF
ELECTC3324 ECA1HHG100B 50V
10µF
CERAMICC3401 ECJ2VC1H561J 50V
560pF
CERAMICC3404 ECJ2VC1H561J 50V
560pF
CERAMICC3407 ECJ2VC1H561J 50V
560pF
CERAMICC3408 ECJ2VC1H561J 50V
560pF
CERAMICC3409 ECJ2VC1H561J 50V
560pF
CERAMICC3410 ECJ2VC1H561J 50V
560pF
CERAMICC3415 ECJ2VC1H102J 50V
1nF
CERAMICC3417 ECJ2VC1H561J 50V
560pF
CERAMICC3418 ECJ2VC1H561J 50V
560pF
CERAMICC3419 ECJ2VC1H561J 50V
560pF
CERAMICC3420 ECJ2VC1H561J 50V
560pF
CERAMICC3425 ECJ2VC1H102J 50V
1nF
CERAMICC3427 ECJ2VC1H561J 50V
560pF
CERAMICC3428 ECJ2VC1H561J 50V
560pF
CERAMICC3429 ECJ2VC1H561J 50V
560pF
CERAMICC3430 ECJ2VC1H561J 50V
560pF
CERAMICC3435 ECJ2VC1H102J 50V
1nF
CERAMICC3437 ECJ2VC1H561J 50V
560pF
CERAMICC3440 ECJ2VC1H561J 50V
560pF
CERAMICC3443 ECJ2VC1H561J 50V
560pF
CERAMICC3446 ECJ2VC1H561J 50V
560pF
ELECTC3450 ECEA1AKA221B 10V
220µF
ELECTC3451 ECEA1AKA221B 10V
220µF
ELECT C3452 ECEA1CKA101 16V
100µF
ELECT C3453 ECEA1CKA101 16V
100µF
CERAMICC3454 ECJ2VC1H220J 50V
22pF
CERAMICC3455 ECJ2VC1H220J 50V
22pF
CERAMICC3456 ECJ2VC1H220J 50V
22pF
CERAMICC3457 ECJ2VC1H221J 50V
220pF
CERAMICC3458 ECJ2VC1H221J 50V
220pF
CERAMICC3459 ECJ2VC1H221J 50V
220pF
CERAMICC3480 ECJ2VB1H104K 50V
100nF
CERAMICC3481 ECJ2VB1H104K 50V
100nF
ELECT C3482 ECA1CM471GB 16V
470µF
ELECT C3483 ECA1CM471GB 16V
470µF
ELECT C4801 ECA1HM101GB 50V
100µF
CERAMICC4802 ECJ2VF1C104Z 16V
100nF
FILMC4803 ECQV1H334JL3 50V
330nF
FILMC4804 ECQV1H334JL3 50V
330nF
CERAMICC4805 ECJ2VF1C104Z 16V
100nF
CERAMICC4806 ECJ2VB1H103K 50V
10nF
ELECT C4807 ECA1HM4R7GB 50V
4.7µF
ELECT C4808 ECA1HM4R7GB 50V
4.7µF
CERAMICC4809 ECJ2VB1H103K 50V
10nF
TERMINALS AND LINKS
AUDIO TERMINAL . TJS59034
AV TERMINAL JK3102 TJB8E026
SCART SOCKET JK3401 0350536400
SCART SOCKET JK3402 0350536400
SCART SOCKET JK3403 0350536400
RCA TERMINAL(3P)JK3405 TJB8E015
RCA TERMINAL(3P)JK3406 TJB8E015
OPTICAL CONNECTORJK3407 TORX178B
OPTICAL CONNECTORJK3408 TORX178B
FS LINK R868 TSF19252
FS LINK R874 TSF19402
FS LINK R2405 TSF19252
FS LINK R2419 TSF19402
FS LINK R2420 TSF19252
SWITCHES
SWITCH S840 ESB92S11B
SWITCH S1003 EVQ23405R
SWITCH S1004 EVQ23405R
SWITCH S1005 EVQ23405R
SWITCH S1006 EVQ23405R
SWITCH S1007 EVQ23405R
RELAYS
RELAY RL801 K6B1ADA00010
RELAY RL802 K6B2ADA00004
DIFFERENCES FOR MODEL TX--28PB50
EXPLODED VIEW
A P.C.B. 19 TNPH0348BK
ANODE CABLE 20 ZTBZAD550A
BACK COVER 21 TKU8E00682
C.R.T. 22 W66EKT10X71
CABINET 23 TKY8E560-1
CONTROL BRACKET 24 TMW8E045
D P.C.B. 25 TNPH0349AM
DEGAUSS COIL 26 TLK8E05175
FBT 28 ZTFM77020A
FOCUS LEAD ASSEMBLY 29 TXJF0C0CJFG
G P.C.B. 30 TNP8EG004AA
L P.C.B. 31 TNPA1726AC
MODEL LABEL 32 TQF8E3197-1
PANASONIC BADGE 33 TBMA060
MISCELLANEOUS COMPONENTS
SET FOOT (FRONT) . TBLG3019
SET FOOT (REAR) . TBLG3020
PRESET LABELRIGHT. TBM8E2138
LID SWITCH . TEK6935
CRT EARTH SPRING . TES2298
AV COVER . TKP8E1338
SPEAKER PANELEFT . TKP8E1371
SPEAKER PANELRIGHT. TKP8E1376
BOTTOM PANEL LEFT. TKP8E1380
BOTTOM PANEL RIGHT. TKP8E1391-1
CARTON . TPC8E4906
TOP CUSHON . TPD8E757
BOTTOM CUSHION . TPD8E758
VIDEO CABINET . VS-28PBL
INSTRUCTION BOOKS
ENGLISH TQB8E3297
I.C.s
VERTICAL OUTPUT IC451 LA7845N
EAROM * IC1104 X24BR200-3MA
REGULATOR IC IC1252 PQ30RV2B
VIDEO PROCESSOR/SYNC GIC1301 C1AB00001494
VIDEO PROCESSOR/SYNC GIC1304 C1AB00001494
REGULATOR IC IC2402 PQ30RV2B
COILS
COIL L558 EXCELDR35C
COIL L574 ELHKLB070B
COIL L576 ELC18B221F
COIL L579 ELHKLB061B
CHOKE COIL L702 ELC18B121G
RESISTORS
S.M.CARBJSA81 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR353 ERJ6ENF1331 0.1W 1% 330
S.M.CARBR363 ERJ6ENF1331 0.1W 1% 330
S.M.CARBR372 ERJ6ENF1331 0.1W 1% 330
34
