Panasonic TX-32PD30D - Page 15

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
VIDEO SWITCH IC3004 C0ZBZ0000451
OUTPUT AUDIO SWITCHIC3006 C1BB00000712
OUTPUT AUDIO SWITCHIC3007 C1BB00000712
8V REGULATOR IC3008 AN78L08TA
VIDEO SWITCH IC3401 NJM2283MTE1
2 INPUT 3 CHANNEL VIDEOIC3402 NJM2286MTE1
R.G.B. OUTPUT IC3801 C1AA00000602
R.G.B. OUTPUT IC3802 C1AA00000602
R.G.B. OUTPUT IC3803 C1AA00000602
GEOMAGNETIC CORRECTIONIC4801 C0AABB000107
PURITY CORRECTIONIC4802 C0AABB000107
LED RECEIVER RM1001 PNA4601M04TV
FUSES
FUSE HOLDER F801-2 EYF52BC
FUSE HOLDER F801-1 EYF52BC
FUSE F801 XBA2C50TH15
DIODES
DIODE D001 MAZ31500HL
DIODE D002 MAZ31500HL
3 TERM CHIP DIODED004 MA3X152K0L
DIODE D008 MAZ402000F
DIODE D009 MAZ402000F
DIODE D353 MAZ31100LL
DIODE D358 MA3X151K0L
DIODE D360 B0EAKM000058
DIODE D361 MA3X151K0L
DIODE D362 MA3X151K0L
DIODE D363 MA3X151K0L
DIODE D367 MAZ30620ML
DIODE D368 MAZ30620ML
DIODE D369 MAZ30620ML
DIODE D450 EU02AV1
3 TERM CHIP DIODED451 MA3X152K0L
3 TERM CHIP DIODED452 MA3X152K0L
DIODE D453 EU02AV1
DIODE D454 B0JAME000052
DIODE D501 B0JAME000052
DIODE D502 MAZ40560LF
DIODE D503 B0HALP000002
DIODE D523 MA2C165001VT
DIODE D524 MA2C165001VT
DIODE D525 RP1HLFA5
DIODE D551 EU02
DIODE D553 B0KZ00000001
DIODE D554 RU3ANLFA1
DIODE D565 MA2C165001VT
DIODE D571 AU02V0
DIODE D581 MA2C165001VT
DIODE D582 MA2C16700E
DIODE D584 MAZ43600HF
DIODE D586 MA2B18200E
DIODE D587 MA2C165001VT
DIODE D741 B0HALP000002
DIODE D752 MA2C165001VT
DIODE D753 MA2C165001VT
DIODE D761 MAZ41500MF
DIODE D762 B0AAGR000002
DIODE D771 B0EAKM000058
DIODE D772 MAZ4104J0F
DIODE D773 MA2C165001VT
DIODE D776 MA2C165001VT
DIODE D781 MA2C16700E
DIODE D791 AU02V0
DIODE D792 MA2C165001VT
AC BRIDGE RECTIFIERD802 D6SB80-4
DIODE D803 MA2C165001VT
DIODE D807 MA2C165001VT
DIODE D809 MAZ20820A0LS
DIODE D811 MAZ20820A0LS
DIODE D812 MAZ22400B0LS
DIODE D814 B0HAGP000003
DIODE D815 B0EAEV000001
DIODE D819 B0HAGP000003
DIODE D821 B0HAGP000003
DIODE D823 PC123FY2
DIODE D832 RK34LFC4
DIODE D840 ERC05-10
DIODE D841 PC123FY2
DIODE D843 ERC05-10
DIODE D844 TVSSR2KL
DIODE D845 RY24V1
DIODE D847 B0EAEV000001
DIODE D850 MAZ40300LF
DIODE D851 B0JBRK000005
DIODE D852 RU2AMLFA1
DIODE D853 EU2YXV0
DIODE D855 FMGG2CSLF665
DIODE D856 EU02
DIODE D857 FMGG26S
DIODE D858 MA2C165001VT
DIODE D859 MA2C165001VT
DIODE D860 RK34LFD2
DIODE D877 MA2C16700E
DIODE D883 EU02
DIODE D884 MA2C165001VT
DIODE D885 MAZ40560HF
DIODE D900 MAZ41300MF
3 TERM CHIP DIODED1001 MA3X152K0L
3 TERM CHIP DIODED1002 MA3X152K0L
DIODE D1004 MAZ30620ML
3 TERM CHIP DIODED1005 MA3X152K0L
DIODE D1008 MTZJT-775.6B
DIODE D1051 LN21RCPH
3 TERM CHIP DIODED1300 MA3X152K0L
3 TERM CHIP DIODED1301 MA3X152K0L
3 TERM CHIP DIODED1302 MA3X152K0L
3 TERM CHIP DIODED1303 MA3X152K0L
3 TERM CHIP DIODED1304 MA3X152K0L
3 TERM CHIP DIODED1306 MA3X152K0L
3 TERM CHIP DIODED1307 MA3X704A0L
DIODE D2002 MAZ30330LL
DIODE D2301 MA2C16700E
DIODE D2302 MA2C16700E
3 TERM CHIP DIODED2303 MA3X152K0L
DIODE D2305 B0BA5R600016
3 TERM CHIP DIODED2306 MA3X152K0L
3 TERM CHIP DIODED2308 MA3X152K0L
DIODE D2310 MAZ30560HL
DIODE D2311 MA2C700A0F
DIODE D2312 MA2C700A0F
DIODE D2313 EU02
DIODE D2314 MA3039HTX
3 TERM CHIP DIODED2315 MA3X152K0L
DIODE D3001 MAZ30680ML
DIODE D3004 MAZ31100LL
DIODE D3103 MA2C165001VT
DIODE D3104 MA2C165001VT
DIODE D3401 MAZ31200ML
DIODE D3402 MAZ31200ML
DIODE D3403 MAZ31200ML
DIODE D3406 MAZ31200ML
DIODE D3801 MA188TA5
15
