Panasonic TX-32PK20F - Replacement Parts List; Ersatzteilliste; Important Safety Notice

Teile, die mit einen Hinweis gekennzeichnet sind
wichtig für die Sicherhet. Solite ein Auswechsein
erfordelrich sein, sind unbdingt Originalteile
einzusetzen.
Bei der Bestellung von Ersatzteilen, di mit *
gekennzeichnet sind, geben Sie bitte unbedingt die
vollständi
g
e T
y
penbezeicnun
g
mit an.
Components Identified by mark have special
characteristics important for safety.
When replacing any of these components, use only
manufacturers specified parts.
* In case of ordering these spare parts, please
always add the complete Model-Type number to
y
our order.
Important Safety Notice
ERSATZTEILLISTE
REPLACEMENT PARTS LIST
Wichti
g
er Sicherhitshinweis
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
COMMON PARTS
MECHANICAL PARTS
SPEAKER LEFT 1 EAB10106DL
SPEAKER RIGHT 2 EAB10106DR
TUNER 3 ENG29505GR
REMOTE CONTROL 4 EUR511211
PANASONIC BADGE 5 TBMA060
POWER BUTTON 6 TBX8E068
REAR AV PANEL 7 TKP8E1253-3
SPEAKER NET 8 TKP8E1285
DOOR LID 9 TKP8E1316
BACK COVER 10 TKU8E00480
CABINET 11 TKY8E390
DEGAUSS COIL 12 TLK8E05123
CONTROL BRACKET 13 TMW8E031
CHASSIS FRAME 14 TMX8E034
M P.C.B. 15 TNP8EM022AC
Z P.C.B. 16 TNP8EZ001AA
D P.C.B. 17 TNPA0876AP
H P.C.B. 18 TNPA1047AC
F P.C.B. 19 TNPA1068AG
Y P.C.B. 20 TNPA1353AN
POWER CORD 21 TSX8E0033
FOCUS LEAD ASSY 22 TXJ/FC0DDG
BATTERY COVER (REMOTE) 23 UR51EC904A
CRT FIXING SCREW 24 VP19151
C.R.T. 25 W76LPX955X05
ANODE CABLE 26 ZTBZAD550A
F.B.T. 27 ZTFL77002A
MISCELLANEOUS COMPONENTS
IC SOCKET . 832AG11D-ESL
IC SOCKET . PCSZT-084A-1
PRESET LABEL . TBM8E1935
BLANKING LABEL . TBM8E1936-1
LID CATCH. TEK6940
POWER BUTTON SPRING . TES8E019
LED COVER . TKP8E1288
I.R. COVER . TKP8E1300
GEOMAGNETIC COIL. TLK8E05124
CLAMPER . TMM76526-1
FIXING CLAMP . TMM81416
LED HOLDER . TMW8E030
P.C.B. BRACKET . TMX8E025
OUTER CARTON . TPC8E4750
TOP CUSHION . TPD8E689
BOTTOM CUSHION . TPD8E690
SUB CUSHION . TPD8E703
BATTERY PACK . UM-3DJ-2P
THERMISTOR R805 232266296706
I.C.s
AUDIO OUTPUT IC251 LA4282
RGB OUTPUT IC351 TDA6111Q-N4
RGB OUTPUT IC361 TDA6111Q-N4
RGB OUTPUT IC371 TDA6111Q-N4
REGULATOR IC381 TL431CLPM
VERTICAL OUTPUT IC451 LA7845N
VIDEO PROCESSOR IC601 TDA9330HN1G
POWER SUPPLY IC801 AN8029
ERROR AMPLIFIER IC845 SE140N
REGULATOR IC852 TL431CLPM
LED RECEIVER IC1011 RPM-637CBRL
MICRO PROCESSOR IC1101 SDA5450C59
SRAM IC1103 KM681000CLP
EPROM * IC1104 27C2001-H15
RESET IC1105 MN1381-R(TA)
RESET IC1106 MN1381-R(TA)
VIDEO PROCESSOR IC1502 VPC3215CB8TP
CIP IC1503 MB87F1720
DFU IC1504 FJB007S
VP2S IC1505 MB87F2131
3.5V REGULATOR IC1506 AN77L035M-E1
MEMORY IC1507 MB87H2010
CLOCK CONVERTOR IC1509 TLC2932IPWL
CIP IC1510 MB87F1720
EARTH CORRECTION IC1901 LA6515
AUDIO PROCESSOR IC2101 MSP3410DPPC5
OPERATIONAL AMPLIFIER IC2201 AN6554NSF-E2
OPERATIONAL AMPLIFIER IC2221 AN6554NSF-E2
H.P. AMPLIFIER IC2351 AN7108
VIDEO SWITCHIC3001 TEA6415C
9V REGULATOR IC3801 AN7809FLB
8V REGULATOR IC3802 AN7708FLB
8V REGULATOR IC3805 AN7808LB
3.5V REGULATOR IC3806 SI-3033C
DYNAMIC FOCUS IC3901 AN5422K
FUSES
FUSE HOLDERF840-2 EYF52BC
FUSE HOLDERF840-1 EYF52BC
FUSEF840 XBA2C50TH15
FUSE F845 TR5-T3150
FUSEF846 TR5-T1250
DIODES
DIODE D001 MA4020
DIODE D002 MA4020
DIODED252 MA165TA5
DIODE D253 MA700TA5
DIODE D254 MA700TA5
DIODED255 MA165TA5
16
