DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
SCART SOCKET JK3401 350536400
SCART SOCKET JK3402 350536400
SCART SOCKET JK3403 350536400
FS LINK R847 TSF19252
FS LINK R848 TSF19402
FS LINK R1914 TSF19161
SWITCHES
SWITCH S840 ESB92S11B
SWITCHS1071 EVQ23405R
SWITCHS1072 EVQ23405R
SWITCHS1073 EVQ23405R
SWITCHS1074 EVQ23405R
SWITCHS1075 EVQ23405R
RELAYS
RELAY RL801 TSE1885-1
DIFFERENCES FOR MODEL TX--32PK20D
MECHANICAL PARTS
E P.C.B. 28 TNPH0176CQ
MODEL LABEL 29 TQF8E3066
INSTRUCTION BOOKS
GERMAN . TQB8E3088A-1
ITALIAN . TQB8E3088C-1
FRENCH . TQB8E3088D-1
I.C.s
EAROM * IC1102 X24RD5-02DD
DIFFERENCES FOR MODEL TX--32PK20F
MECHANICAL PARTS
E P.C.B. 28 TNPH0176CK
MODEL LABEL 29 TQF8E3041
INSTRUCTION BOOKS
GERMAN/SPANISH . TQB8E3041AE1
DUTCH/FRENCH . TQB8E3041BD1
SWEDISH/NORG. . TQB8E3041FG1
SUOMI/DANISH . TQB8E3041HK1
PORTUGUESE . TQB8E3041J-1
I.C.s
EAROM * IC1102 X24RD5-02ED
