SERVICE HINTS
How to remove the rear cover
1. Remove the 12 [10] screws as shown in Fig.2.
LOCATION OF CONTROLS
L-Board
A-Board
3
Fig. 2
Fig. 3
G-Board
Focus
Screen D-Board
SCREWS
SCREWS
